Autoscaling LLM Inference: Queue, KV Cache, Concurrency

Why GPU utilization lies for LLM serving

The default Kubernetes autoscaling signal, CPU utilization, says almost nothing about an inference pod whose work happens on a GPU. The obvious replacement, GPU utilization, is not much better. NVML defines the gpu utilization field as the "percent of time over the past sample period during which one or more kernels was executing on the GPU" ^[1]. It measures whether the device is busy, not how much more work it can absorb.

A continuous-batching engine such as vLLM launches a forward pass on every scheduler step while any request is in flight. By the NVML definition, a replica serving a handful of streams and a replica serving its maximum batch can both read close to 100%, because in both cases a kernel is almost always executing. That is our reading of the definition, and it matches Red Hat's guidance for KServe and vLLM, which notes that "a high GPU utilization might indicate efficient usage of accelerators or it can also signify reaching a saturated state" ^[2].

The signals that move with load sit inside the serving engine. vLLM's metrics design notes say that "a common use case for our metrics is to support automated scaling of vLLM instances" ^[3].

Signal candidates

The first four feed HPA or KEDA directly; latency targets suit a capacity-modelling controller such as Dynamo's Planner. Metric definitions are in our inference metrics guide.

What vLLM exposes

vLLM serves Prometheus metrics on the /metrics endpoint of its OpenAI-compatible API server ^[4]. The current list includes the gauges above, vllm:num_requests_waiting_by_reason, the counter vllm:num_preemptions and vllm:request_queue_time_seconds ^[4]. The design page defines vllm:kv_cache_usage_perc as the "fraction of used KV cache blocks (0–1)" ^[3].

Names change across releases, and queries copied from older posts break silently. As of 2026-10-28:

The Red Hat KServe example from September 2025 still lists vllm:gpu_cache_usage_perc among its candidate metrics ^[2]. The swap-related vllm:num_requests_swapped and vllm:cpu_cache_usage_perc are described as legacy from a preemption mode that is "no longer relevant in v1" ^[3]. vLLM's policy is that metrics deprecated in version X.Y are hidden in X.Y+1 and can be re-enabled with --show-hidden-metrics-for-version=X.Y ^[4].

Check the running binary before writing a query:

curl -s http://<pod-ip>:8000/metrics | grep -E '^vllm:(num_requests_(running|waiting)|kv_cache_usage_perc|gpu_cache_usage_perc|num_preemptions)'

A KEDA query that returns no series for a renamed metric does not fail loudly: ignoreNullValues defaults to true, "which means ignoring the empty value list from Prometheus"; set it to "false" and the scaler returns an error when the target is lost ^[5].

HPA math with custom and external metrics

The HPA controller computes ^[6]:

desiredReplicas = ceil( currentReplicas × currentMetricValue / desiredMetricValue )

It skips scaling when the ratio is within a tolerance of 1.0, which is 0.1 by default. The per-HPA behavior.scaleUp.tolerance / behavior.scaleDown.tolerance field is stable since Kubernetes v1.37 (first available in v1.33); without it, the cluster-wide --horizontal-pod-autoscaler-tolerance flag applies ^[6]. The controller evaluates every 15 seconds by default (--horizontal-pod-autoscaler-sync-period), and with several metrics it computes a replica count for each and takes the largest ^[6].

Two details matter for GPU pods. For external and object metrics, the replica count used is the number of Running and Ready Pods ^[6], so pods still loading weights do not count. And for an external metric with an AverageValue target, the metric value is divided by the pod count before comparison ^[6]. The query should therefore return a fleet total (sum(...)), not an average, when the target is per-pod.

Worked example 1: queue depth

Target: 2 waiting requests per Ready replica (AverageValue: 2), the same threshold Red Hat's example uses ^[2]. Four Ready replicas.

• Total waiting = 20. Average = 20 / 4 = 5. Ratio = 5 / 2 = 2.5. Desired = ceil(4 × 2.5) = 10.
• Total waiting = 9. Average = 2.25. Ratio = 1.125, outside the 0.1 tolerance. Desired = ceil(4.5) = 5.
• Total waiting = 8.6 (a rate-smoothed query). Average = 2.15. Ratio = 1.075, inside tolerance. No action.

The default scale-up policy allows the larger of +100% or +4 pods per 15 seconds ^[6], so 4 → 10 takes two periods (4 → 8 → 10). Weight loading, not arithmetic, is the bottleneck.

Queue depth has a structural problem: it is an integral of overload. While new pods load, the queue keeps growing, the HPA keeps computing against only the Ready pods, and the desired count keeps rising. If the queue reaches 60 before any new pod is Ready, the next evaluation asks for ceil(4 × 60/4/2) = 30 replicas. Without a sensible maxReplicas, queue depth overshoots after slow warmups.

Worked example 2: KV cache usage is a bounded ratio

Target: average KV usage 0.80 (Value type on avg(vllm:kv_cache_usage_perc)). Because the metric cannot exceed 1.0, the largest ratio it can produce is 1.0 / 0.80 = 1.25. Each decision can therefore add at most 25% of current Ready replicas:

Each step waits for the previous pods to become Ready, so 4 to roughly 10 replicas takes three warmups. Pair KV usage with an unbounded signal; since HPA takes the maximum across metrics, KV then acts as a floor.

Worked example 3: in-flight concurrency and Little's law

In-flight requests (running + waiting) are proportional to load. Little's law, L = λW ^[7], says the average number in the system equals arrival rate times average time in the system. The numbers below are hypothetical; replace them with your load test results.

• Load test: one replica meets the TTFT and ITL p99 SLO up to 48 concurrent requests (the knee). Mean request duration W = 12 s.
• Target set at 40 per replica (about 83% of the knee).
• Arrivals λ = 10 req/s → L = 10 × 12 = 120 in flight → 120 / 40 = 3 replicas.
• Arrivals rise to λ = 16 req/s → L = 192 (assuming W stays at 12 s) → with 3 replicas the average is 64, ratio 1.6, desired = ceil(3 × 1.6) = 5. Check: 192 / 5 = 38.4 per replica, under the knee.

In practice W rises near saturation, so L grows faster than λ: the signal strengthens just when it matters.

KEDA Prometheus trigger

KEDA's Prometheus scaler takes a serverAddress, a query that "must return a vector/scalar single element response," a threshold ("value to start scaling for," float allowed) and an optional activationThreshold (default 0) ^[5]. Trigger metricType defaults to AverageValue; pollingInterval defaults to 30 seconds; cooldownPeriod defaults to 300 seconds and applies only when scaling to zero; minReplicaCount defaults to 0 ^[8]. Scaling between 1 and N replicas is delegated to an HPA that KEDA creates, and advanced.horizontalPodAutoscalerConfig.behavior is passed straight to the HPA's behavior field ^[8].

A ScaledObject that combines the concurrency and KV signals from the examples above:

apiVersion: keda.sh/v1alpha1
kind: ScaledObject
metadata:
  name: llama-vllm
spec:
  scaleTargetRef:
    name: llama-vllm
  minReplicaCount: 2
  maxReplicaCount: 12          # = GPU quota / GPUs per replica
  pollingInterval: 15
  advanced:
    horizontalPodAutoscalerConfig:
      behavior:
        scaleDown:
          stabilizationWindowSeconds: 900
          policies:
            - type: Pods
              value: 1
              periodSeconds: 120
  triggers:
    - type: prometheus
      metricType: AverageValue   # sum / Ready pods vs threshold
      metadata:
        serverAddress: http://prometheus.monitoring:9090
        query: |
          sum(vllm:num_requests_running{namespace="llm",model_name="llama"})
          + sum(vllm:num_requests_waiting{namespace="llm",model_name="llama"})
        threshold: "40"
        ignoreNullValues: "false"
    - type: prometheus
      metricType: Value          # fleet average vs target
      metadata:
        serverAddress: http://prometheus.monitoring:9090
        query: avg(vllm:kv_cache_usage_perc{namespace="llm",model_name="llama"})
        threshold: "0.8"

The thresholds and the 900-second window are the illustrative values from this article, not recommendations for your hardware. For scale-to-zero, activationThreshold decides the 0 ↔ 1 transition and "has more priority than the scaling value"; activation happens only when the value is strictly greater than the setting ^[9]. A metric served by the pods themselves reads nothing at zero replicas, so scale-from-zero needs a signal that exists without pods, such as a gateway or queue metric. Native HPA has the same rule: from Kubernetes v1.37 minReplicas: 0 is beta and on by default, but only for object and external metrics ^[6]. The cost side of that decision is in our scale-to-zero and cold start analysis.

Stabilization, flapping and warmup

The HPA defaults are asymmetric. Scale-down uses a 300-second stabilization window and allows removal of 100% of replicas per 15 seconds; scale-up has no stabilization window and is applied immediately, up to +100% or +4 pods per 15 seconds, whichever is larger ^[6]. Within the window the controller picks the highest recommendation, so scale-downs are gradual ^[6].

Those defaults suit pods that start in seconds. A GPU replica that takes minutes to load weights and capture CUDA graphs pays a full warmup for every premature scale-down, and a burst during warmup becomes a backlog.

Backlog arithmetic

Continue the hypothetical from example 3. Each replica's capacity at the knee is μ = 48 / 12 = 4 req/s, so 3 replicas serve 12 req/s. Arrivals jump to 16 req/s, and a new replica takes 240 s to become Ready (measure yours; the cold start analysis breaks the stages down).

• Excess arrivals: 16 − 12 = 4 req/s.
• Backlog at the moment new capacity arrives: 4 × 240 = 960 queued requests.

Three ways to absorb it:

1. Headroom in the target. A per-replica target T against a knee K absorbs a step of up to K/T − 1 with no queueing. At T = 40, K = 48 that is 20%. To absorb a 60% step (10 → 16 req/s) for the whole warmup, T ≤ 48 / 1.6 = 30, which means 120 / 30 = 4 replicas at baseline instead of 3: 33% more GPUs held warm.
2. Shorter warmup. Local weight caches and GPU memory snapshots shrink the window.
3. Shed or defer. Gateway admission control, or a delay-tolerant queue for batch traffic.

Scale-down settings

Our judgment for slow-warming GPU pods: a scale-down window at least as long as warmup plus the typical gap between bursts, and a Pods policy removing one replica per period. Kubernetes gives a pod 30 seconds to terminate gracefully by default ^[10]. A request with max_tokens 4096 at a 50 ms ITL needs 4096 × 0.05 = 204.8 s to finish, so a 30-second grace period cuts off long generations on every scale-down. Size terminationGracePeriodSeconds from your longest allowed generation, and set vLLM's --shutdown-timeout. Its default of 0 makes SIGTERM abort in-flight requests; a value above 0 rejects new requests and drains running ones for up to that many seconds (flag added in v0.18.0, 2026-03-20; behaviour read in v0.32.0 source, vllm/v1/engine/core.py). Keep it below the grace period.

Dynamo Planner

NVIDIA Dynamo's Planner is an SLA-aware alternative to HPA/KEDA for Dynamo deployments. Facts below are from the v1.6.1 documentation (the latest URL redirects to a dev build as of 2026-10-28) ^[11]:

The sla target requires kube-prometheus-stack on Kubernetes, and profiling is recommended rather than required ^[11]. The default max_gpu_budget of 8 is hit quickly by a multi-GPU model, so set it on purpose. The dual loop mirrors the headroom pattern above: a slow forecast-driven floor plus a fast reactive layer.

Prefill and decode pools

Prefill is compute-bound and decode is memory-bound; Dynamo's docs state that "a single replica count doesn't capture both" and let you set separate floors with prefill_min_endpoint and decode_min_endpoint (^[12]; v1.6.1). In a disaggregated deployment, scale each pool on the signal that saturates it:

The ratio between the pools follows the input/output token mix, not a fixed number. Whether to disaggregate at all is a cost question covered in prefill/decode disaggregation break-even.

Load test to find thresholds

Every threshold above depends on a per-replica knee measured on your stack and traffic mix:

1. Fix the replica configuration (model, tensor_parallel_size, max_num_seqs, max_num_batched_tokens, gpu_memory_utilization).
2. Replay a prompt/output length distribution sampled from production. vllm bench serve supports --request-rate (Poisson arrivals by default, inf sends everything at once), --burstiness for Gamma-distributed arrivals, and --max-concurrency to cap outstanding requests ^[13].
3. Step rate or concurrency upward, recording client TTFT/ITL p99 and the vLLM gauges and preemption rate.
4. The knee K is the highest step that still meets both p99 SLOs with zero preemptions.
5. Set the concurrency target at K / (1 + expected step size during one warmup), per the headroom arithmetic. Set the KV target slightly below the KV usage observed at K.
6. Re-run after engine upgrades.

KV capacity per replica can be estimated beforehand with our vLLM KV cache capacity planner.

Failure modes and guardrails
