LLM Load Testing: Open vs Closed Loop and Goodput

Why most LLM benchmarks mislead

The most common LLM serving benchmark is a concurrency sweep: N simulated clients each send a request, wait for the full response, and send the next one, with N stepped through 1, 8, 32, 128. It answers a narrow question: how much throughput the server delivers when the load generator politely waits for it. It does not answer what a capacity plan or SLO sign-off asks, which is what happens to time to first token (TTFT) and per-token latency when users arrive at a given rate regardless of how busy the server is. The gap between the two answers is widest near saturation, exactly where it matters.

Three design errors account for most misleading results. The arrival model: a fixed-concurrency generator slows down whenever the server slows down, so it never reproduces the queueing collapse real traffic causes. Measurement bias known as coordinated omission: the generator stops sending during a stall and records almost no slow samples. Workload shape: one fixed prompt length and one fixed output length, which removes the variance that drives batching and KV-cache pressure. This guide treats the benchmark as experiment design first, then maps each choice onto vllm bench serve, GuideLLM and AIPerf, as documented on 2026-10-28 (vLLM "latest" docs and v0.32.0 source, GuideLLM v0.8.x, AIPerf v0.13.0). These tools change monthly; flag names should be rechecked against --help before a run.

Closed loop vs open loop

A closed-loop generator holds a fixed population of N clients, each issuing a request only after its previous response completes (optionally after a "think time"). In-flight requests never exceed N, and the arrival rate is an output of the experiment, not an input. An open-loop generator issues requests on a schedule independent of completions, so the number in flight is unbounded and is itself a measured outcome.

Schroeder, Wierman and Harchol-Balter made this distinction the subject of an NSDI 2006 paper ^[1]. Their case studies were web servers, databases and an auction site, not LLM servers, but the principles transfer. Principle (i): "For a given load, mean response times are significantly lower in closed systems than in open systems." Principle (ii): as the multiprogramming level (MPL, the client count N) grows, closed systems approach open behaviour, "but convergence is slow for practical purposes." Principle (iii): variability has a large effect in open systems and a much smaller one in closed systems. They also describe a partly-open model, in which users arrive openly and then issue a session of requests in closed fashion, and give a rule of thumb that it behaves like an open system when sessions average 5 or fewer requests and like a closed system at 10 or more ^[1].

The two models answer different questions, and both are legitimate:

A public chat endpoint or multi-tenant API is closer to row 3; a batch pipeline with a fixed worker pool is genuinely closed (row 1), which is why closed-loop numbers fit offline jobs (see the batch vs real-time sizing analysis).

Little's law: the arithmetic that links the two

Little's law states that the average number of items in a queueing system, L, equals the average arrival rate, λ, times the average time an item spends in the system, W: L = λW ^[2]. It holds regardless of arrival distribution, which makes it the conversion factor between concurrency and rate.

Worked example 1, sizing the concurrency a forecast implies (illustrative). Assume a forecast peak of λ = 6 requests/s and a mean end-to-end latency of W = 15 s (for example about 0.5 s TTFT plus 500 output tokens at about 29 ms per token). Then L = 6 × 15 = 90 requests in flight on average. A closed-loop test that stops at N = 32 never observes the operating point the forecast implies.

Worked example 2, how closed loop self-throttles (illustrative). A closed-loop test with N = 64 and zero think time measures mean latency W = 20 s. By Little's law its throughput is X = N / W = 64 / 20 = 3.2 requests/s. Suppose a configuration change makes the server slower and W rises to 32 s. The generator now offers X = 64 / 32 = 2.0 requests/s, a 37.5% load reduction it applied to itself. Real users would not have slowed down; production would have seen a queue.

Worked example 3, open-loop overload (illustrative). An open-loop test offers λ = 4 requests/s to a deployment whose sustainable completion rate is μ = 3.5 requests/s. The backlog grows by 4 − 3.5 = 0.5 requests every second. After a 600 s run, about 0.5 × 600 = 300 requests are queued beyond what the engine can work on, and a request arriving at the end waits on the order of 300 / 3.5 ≈ 86 s before its share of service begins. The run has no steady state, which gives a practical diagnostic: if p99 TTFT grows when the same rate runs twice as long, the offered rate exceeds capacity and the number is not a latency measurement.

Coordinated omission, with numbers

Gil Tene's wrk2 README describes the effect precisely: in a wait-for-response design, "high latency responses result in the load generator coordinating with the server to avoid measurement during high latency periods." wrk2's remedy is a constant-throughput schedule that "measures response latency from the time the transmission should have occurred" ^[3].

Worked example 4 (illustrative, simplified). One closed-loop client, normal latency 0.1 s, 200 s run, a single 50 s server stall starting at t = 100 s.

• Closed loop: about 1,000 samples at 0.1 s before the stall, one sample at about 50 s, and about 500 samples at 0.1 s after. Of about 1,501 samples, one is slow. The p99 is 0.1 s and the mean is (100 + 50 + 50) / 1,501 ≈ 0.13 s. Only the maximum reveals the stall.
• Open loop at an intended 10 requests/s: 2,000 requests are scheduled, 500 of them during the stall. Measured from their intended send time, those 500 see latencies spread roughly uniformly from about 50 s down to 0.1 s (assuming, as a simplification, that the backlog drains immediately when the stall ends). Now 25% of samples are slow, the p99 (the 20 slowest samples) is about 48 s, and the mean is (1,500 × 0.1 + 500 × 25) / 2,000 ≈ 6.3 s.

Same server, same stall: p99 of 0.1 s versus about 48 s. LLM engines rarely stall for 50 s, but KV-cache preemption and long prefills produce the same pattern at smaller scale. Since vLLM v0.30.0 (2026-09-22), when --max-concurrency is set the client records client_queue_time = start_time - request_arrival_time, and with a finite request rate it also reports e2el_including_client_queue, the latency measured from the scheduled arrival rather than from the actual send ^[4]. That metric is the coordinated-omission-corrected view and should be requested explicitly via --percentile-metrics ^[5].

Arrival processes: constant, Poisson, gamma

A constant process spaces requests exactly 1/λ apart. A Poisson process draws exponential inter-arrival times with mean 1/λ, giving a coefficient of variation (CV, standard deviation over mean) of 1; it is the standard model for many independent users. A gamma process generalises both. vLLM's implementation samples each interval as np.random.gamma(shape=burstiness, scale=theta) with theta = 1.0 / (current_request_rate * burstiness) ^[4]. With shape k and scale 1/(λk), the mean interval is k × 1/(λk) = 1/λ for every k, the variance is k × (1/(λk))² = 1/(λ²k), and the CV is 1/√k.

Derived from the gamma formulas above; the rate is illustrative.

All four offer the same average load; principle (iii) predicts that row 1 will show worse tail latency than row 4. vLLM documents --burstiness as defaulting to 1.0, which "follows Poisson process", with values below 1 more bursty and above 1 more uniform ^[5]. AIPerf exposes --arrival-pattern with constant, poisson (the default) and gamma, plus --arrival-smoothness, which its reference describes as "Compatible with vLLM's --burstiness parameter (same value = same distribution)" ^[6]. GuideLLM offers constant and poisson profiles with the rate set inside the profile spec, for example --profile kind=constant,rate=10 ^[7]; v0.8.1 (2026-10-08) has no gamma strategy.

One default deserves attention: vLLM's --request-rate defaults to inf, and "If this is inf, then all the requests are sent at time 0" ^[5]. Combined with the default --num-prompts of 1000, an unconfigured run is a single 1,000-request burst. That measures drain throughput, not latency at any meaningful offered load.

Concurrency caps and what they do

Adding a concurrency cap to a rate-driven test produces a hybrid: arrivals are scheduled openly, but a client-side semaphore admits only K at a time. This models a gateway or a fixed connection pool, and it is valid when production has such a component. The cost is that the cap reintroduces closed-loop throttling at the client. vLLM's help text states that with both flags set, "the actual request rate may be lower than specified … if the server is not processing requests fast enough to keep up"; --max-concurrency has no default, so concurrency is otherwise unlimited ^[5][8]. In AIPerf, --concurrency alone is closed loop ("AIPerf issues a new request immediately when one completes"), while with --request-rate it "acts as a ceiling; requests scheduled by rate are blocked if at limit" ^[9][6]. The AIPerf README calls this combination "Dual request control" ^[10].

Whenever a cap is active, report achieved rate next to target rate, and latency including client-side queue time: if achieved rate falls below target, the cap set the result, and the client-side wait is user-visible latency that server-side TTFT omits. AIPerf v0.13.0 latencies exclude that wait: it issues a request only after a concurrency slot is free and times latency from the actual send (credit/issuer.py), so ceiling wait is invisible.

Input and output length distributions

Prefill cost scales with input sequence length (ISL), decode cost with output sequence length (OSL), and KV-cache occupancy with both, so fixed lengths remove the variance that makes batching hard. Out of the box, vLLM and AIPerf produce fixed lengths. vLLM's random dataset defaults to --random-input-len 1024, --random-output-len 128 and --random-range-ratio 0.0, which samples lengths from [input_len * (1 - range_ratio), input_len * (1 + range_ratio)], a zero-width range at the default ^[5]. AIPerf synthesises ISL from a normal distribution with --isl defaulting to 550 and --isl-stddev defaulting to 0.0, and only caps output via max_completion_tokens when --osl is set ^[6].

Three levels of realism are available:

Dataset names are from the vLLM bench serve CLI, AIPerf CLI options and GuideLLM v0.8.0 release notes. Trace datasets with timestamps auto-promote AIPerf to --fixed-schedule mode, which "replays the exact timing pattern from the dataset"; --no-fixed-schedule keeps the user's chosen timing mode instead ^[6].

Prefix caching is the most frequent hidden variable: random prompts share nothing and understate a cache-enabled engine, while a shared long system prompt overstates it. vLLM's --random-prefix-len adds a fixed shared prefix of chosen length, and AIPerf can synthesise prompts from trace hash_ids to reproduce KV-cache sharing patterns ^[5][6]. Forcing output length with --ignore-eos makes OSL deterministic, which suits regression tests but hides natural stopping variance; the run report should state which was used.

Warm-up, duration and steady state

The first requests of a run pay for cache population and connection setup; the last run against a draining queue. Both transients should be excluded. vLLM's --num-warmups defaults to 0 ^[5]. AIPerf runs a separate warmup phase whose metrics "are discarded", configured with stop conditions such as --warmup-request-count or --warmup-duration ^[11]. GuideLLM accepts warmup and cooldown as fractions or absolute values inside the profile spec ^[7]. GuideLLM v0.8.0 also added a min_requests constraint because a max_requests stop "tails off" at the end of the run, while min_requests keeps the full rate until the counted requests finish ^[12].

Run length should be chosen from the percentile being reported. A p99 from 1,000 requests rests on the 10 slowest samples; a p99.9 from the same run rests on one. As illustrative arithmetic, 10,000 measured requests at 4 requests/s take 2,500 s, about 42 minutes. Repeat runs quantify the rest: AIPerf's --num-profile-runs (1 to 10) computes mean, standard deviation and confidence intervals across runs, at a default confidence level of 0.95 ^[6]. Report percentiles (p50, p90, p99), not means, because the mean of a latency distribution with a queueing tail describes no actual request. vLLM's --metric-percentiles defaults to "99" only, so 50,90,99 should be passed explicitly ^[5].

Goodput and SLO definition

Throughput counts every completed request; goodput counts only those that met their latency targets. DistServe framed serving performance "in terms of the maximum rate that can be served within both TTFT and TPOT constraints on each GPU", and reported serving "7.4x more requests or 12.6x tighter SLO" than prior systems "while staying within latency constraints for > 90% of requests" ^[13]. Those gains are the paper's results for its disaggregated design, not a general expectation (see the disaggregated prefill/decode break-even analysis).

Current tools implement goodput as follows (metric definitions are in the TTFT, ITL and goodput definitions guide):

• vLLM: --goodput takes KEY:VALUE pairs in milliseconds with keys ttft, tpot, e2el ^[5].
• AIPerf: --goodput "time_to_first_token:100 inter_token_latency:3.40", defined as "the number of completed requests per second that meet specified metric constraints" ^[14]; values are in each metric's display unit ^[6].
• GuideLLM (v0.8.0+): an SLO set through --metrics '{"kind":"generative","slo":{"ttft_ms":200,"tpot_ms":50}}' produces a "Goodput Attainment" figure, and a goodput profile "will search for the highest load that can meet the SLO … at some target attainment level" ^[12].

An SLO for capacity purposes needs three parts: per-request thresholds (for example TTFT ≤ 500 ms and TPOT ≤ 50 ms), an attainment level (for example 99% of requests), and the workload it applies to (arrival process, ISL/OSL distribution). Worked example 5 (illustrative): a run at 5 requests/s for 1,200 s completes 6,000 requests; 5,820 meet both thresholds. Goodput is 5,820 / 1,200 = 4.85 requests/s and attainment is 5,820 / 6,000 = 97.0%. Against a 99% attainment target this rate fails, even though raw throughput (5.0 requests/s) matched the offered load.

Sweeping to find the knee

Capacity is the highest offered rate that still meets the SLO at the required attainment, found by sweeping rate in an open-loop test and plotting p99 TTFT, p99 TPOT and attainment against offered load. Below the knee, latency is nearly flat; beyond it, Worked example 3 applies and latency grows with run length. GuideLLM's sweep profile automates the bracket: it runs synchronous and throughput strategies first, then interpolates rates between them for asynchronous constant or poisson runs ^[15]). Its knee profile instead fits a two-segment line to throughput versus concurrency and reports where throughput stops rising, which is a closed-loop saturation estimate rather than an SLO capacity ^[16]. GuideLLM's over-saturation constraint can stop a run when concurrency and TTFT both trend significantly upward ^[17]. vLLM supports --ramp-up-strategy linear|exponential with --ramp-up-start-rps and --ramp-up-end-rps, and AIPerf accepts comma-separated lists such as --request-rate 10,20,50 to run a sweep (^[5][6]. A ramp mixes load levels in one run, so discrete steady-state steps give cleaner numbers; report the last passing step and show the next one failing.

Tool comparison

Compiled from the tool documentation cited in the sections above.

Reporting template and pitfalls

The minimum publishable record:

Recurring pitfalls: quoting a closed-loop peak as "capacity"; running vLLM with the default infinite rate; reporting means; changing tools mid-baseline (the migrating GenAI-Perf baselines to AIPerf guide covers how to bridge that); running the client on the same host as the server, where it competes for CPU; and treating a run whose p99 grows with duration as a latency result. GPU Smith can review a load-test design against these criteria on request.
