Mapping TP, PP and DP to NVLink and InfiniBand Domains

Per-step traffic formulas for tensor, pipeline, context and data parallelism, where each belongs on NVLink or InfiniBand, and a 405B, 1,024-GPU example.

By GPU Smith

Mapping TP, PP and DP to NVLink and InfiniBand Domains

Summary

  1. 01Keep tensor parallelism inside the NVLink domain: it carries the largest traffic volume and places frequent collectives on the critical path between GEMMs.
  2. 02At fixed GPU count, changing the split between pipeline and data parallelism does not change per-GPU tensor-parallel traffic. It changes bubble time, memory and data-parallel traffic.
  3. 03Place context parallelism close to tensor parallelism, pipeline parallelism across nodes and data parallelism outermost. Rank order decides which dimension crosses an oversubscribed tier.
  4. 04Sequence parallelism reduces replicated activations without increasing tensor-parallel bandwidth. Interleaving reduces pipeline bubbles while multiplying pipeline traffic.
  5. 05An NVL72 domain can hold multiple parallel dimensions, but layer, head and batch divisibility still constrain the layout. Use measured memory headroom and communication overlap to choose between viable candidates.
Inside this article
  1. 01The two-level bandwidth hierarchy
  2. 02Communication volume per parallel dimension
  3. 03Frequency and latency sensitivity
  4. 04Placement rules
  5. 05Sequence parallelism and activation memory
  6. 06Interleaved pipeline schedule
  7. 07Case: 8-GPU HGX node
  8. 08Case: NVL72 domain
  9. 09Worked example: 405B-class dense model on 1,024 H100 GPUs
  10. 10Verifying with NCCL tests and topology
  11. 11Common mistakes
  12. 12Sources

The two-level bandwidth hierarchy

Large training jobs run on two networks: a scale-up NVLink/NVSwitch domain and a scale-out InfiniBand or RoCE fabric with one NIC per GPU. Placement means putting each communication pattern on the network that can carry it. The gap is about an order of magnitude per GPU:

SystemNVLink per GPU (NVIDIA figure)NVLink per directionScale-out NIC per GPUScale-out per directionRatio (per direction)
DGX H100 (8-GPU domain)900 GB/s450 GB/s1 x ConnectX-7, up to 400 Gb/s50 GB/s9x
GB200 NVL72 (72-GPU domain)1,800 GB/s900 GB/s1 x ConnectX-7, 400G50 GB/s18x

The DGX H100 has "4 x 4th generation NVLinks that provide 900 GB/s GPU-to-GPU bandwidth" and eight single-port ConnectX-7 cards at up to 400 Gb/s each [1]. The 900 GB/s figure counts both directions: H100 has 18 NVLink links, each "delivering 25 GB/sec effective bandwidth in each direction" [2], so 18 x 25 = 450 GB/s each way. 400 Gb/s / 8 = 50 GB/s at line rate. For Blackwell, NVIDIA lists 1,800 GB/s NVLink bandwidth per GPU and NVLink GPU domains of 8 or 72 (NVIDIA NVLink, marked preliminary). The same page calls the next generation's per-GPU figure "3 TB/s bidirectional", so 1,800 GB/s is likewise both directions: 900 GB/s each way (18 links x 50 GB/s). A DGX GB200 rack is "18x 1RU compute trays, each with 2 Grace CPUs and 4 Blackwell GPUs", with four ConnectX-7 400G OSFP NICs per tray for the cluster network [3]; the GB300 trays in the same guide use 800G ConnectX-8, which halves the ratio to 9x.

Two consequences follow. A collective that costs 10% of step time on NVLink can dominate it on the NIC. And the fast domain grows from 8 GPUs to 72, which changes which dimensions fit inside it. NVIDIA calls the NVL72 "a 72-GPU NVIDIA NVLink domain that acts as a single, massive GPU" [4]; for placement, the operative fact is that any two of those 72 GPUs see the same NVLink bandwidth, so tray boundaries stop mattering.

For the fabric build that consumes these placement decisions, see fabric sizing, ports and rails.

9xDGX H100 NVLink-to-scale-out bandwidth ratio per direction
18xGB200 NVL72 NVLink-to-scale-out bandwidth ratio per direction
3.06xCalculated activation-memory reduction from SP alone in the worked layer example with selective recomputation
2.9%Calculated layout A pipeline bubble with interleaving in the worked example

Communication volume per parallel dimension

The formulas below come from the Megatron-LM scaling paper [5] and the Llama 3 paper [6]. Notation follows Megatron: microbatch size b, sequence length s, hidden size h, tensor-parallel size t, pipeline-parallel size p, data-parallel size d, microbatches per pipeline per step m = B/(b x d) for global batch B in sequences, and l_stage layers per pipeline stage. Volumes are in elements; multiply by 2 bytes for BF16.

Tensor parallelism (TP). Two all-reduces forward and two backward per layer, each on a tensor of size bsh. The paper gives "a total communication of 8bsh(t-1)/t per layer per device for each microbatch" (times l_stage per stage). Sequence parallelism (SP) replaces each all-reduce with a reduce-scatter plus an all-gather; because a ring all-reduce is itself a reduce-scatter followed by an all-gather, "the communication bandwidth used for tensor parallelism and tensor together with sequence parallelism are the same" [7].

Pipeline parallelism (PP). Point-to-point between consecutive stages: bsh per microbatch, forward and backward. With the paper's scatter/gather optimization, each TP rank sends only bsh/t over its own NIC and the receiver re-assembles the tensor with an NVLink all-gather. Interleaving with v chunks per device multiplies PP traffic by v.

Data parallelism (DP). One reduction per step over the P/(t x p) parameters each GPU holds. With Megatron's distributed optimizer, "each data-parallel rank calls reduce-scatter" after the backward pass and an all-gather rebuilds the parameters after the optimizer step [8]. Ring cost per GPU is (d-1)/d of the buffer for each half.

Context parallelism (CP). Llama 3 splits the sequence and "first all-gather[s] the key (K) and value (V) tensors", arguing that with GQA this is negligible against O(S^2) attention compute.

Expert parallelism (EP). All-to-all token dispatch; its sizing is covered separately in expert parallelism traffic sizing.

Per-GPU, per-step volumes (our algebra; BF16 activations, FP32 gradient reduce-scatter, BF16 parameter all-gather):

DimensionCollectivePer-GPU bytes per training step
TP (with or without SP)all-reduce, or reduce-scatter + all-gatherl_stage x m x 8bsh(t-1)/t x 2
PP (scatter/gather on)send/recvm x v x 2 x (bsh/t) x 2
CP (all-gather K,V; GQA)all-gather fwd, reduce-scatter bwdl_stage x m x 2 x 2bs(h_kv/t)(c-1)/c x 2
DP (distributed optimizer)reduce-scatter + all-gather(P/(t x p)) x (d-1)/d x (4 + 2)

A useful identity drops out of the TP row. Because l_stage = L/p and m = B/(b x d), the TP volume per GPU is L x B x s x h x 8(t-1)/t x 2 / (p x d). For a fixed GPU count n, p x d = n/t, so TP traffic per GPU depends only on t, not on how the remaining GPUs are split between PP and DP. Rebalancing PP against DP moves bubble, memory and DP traffic, never TP traffic.

Frequency and latency sensitivity

Volume is half the story; the other half is how often a collective sits on the critical path.

DimensionOperations per microbatch per layerOn critical path?Overlap available
TP4 all-reduces (8 ops with SP)Yes, between GEMMs in every layerPartial (--tp-comm-overlap)
CP1 all-gather fwd, 1 reduce-scatter bwd (Llama 3 style)Yes, exposed before attentionRing variants overlap with compute
PP2 sends per microbatch per stage boundary (x v)Partly; bubbles hide someAsync p2p
DP1 reduce-scatter + 1 all-gather per step, bucketedMostly no--overlap-grad-reduce, --overlap-param-gather

The overlap flags are from the Megatron Core parallelism guide. The Megatron paper: "data parallelism only needs to perform expensive all-reduce communication once per batch", while tensor parallelism all-reduces "for every microbatch". In Llama 3, the innermost dimension "requires the highest network bandwidth and lowest latency", while PP and DP crossed "a multi-hop network, with latency up to tens of microseconds" [6].

Placement rules

  1. TP inside the NVLink domain. Megatron's Takeaway #1: "tensor model parallelism should generally be used up to degree g when using g-GPU servers, and then pipeline model parallelism can be used to scale up to larger models across servers." Its 161B-parameter experiment found "peak performance when the tensor-parallel size is equal to the number of GPUs in a single node" [5].
  2. CP next, as close as possible. Llama 3 ordered dimensions [TP, CP, PP, DP]. The Megatron Core guide says to "Use CP instead of larger TP for long sequences."
  3. PP across nodes. Pipeline parallelism "uses much cheaper point-to-point communication that can be performed across nodes without bottlenecking the entire computation."
  4. DP outermost. Takeaway #2: choose a model-parallel size t x p so the model fits, and "data parallelism can be used to scale up training to more GPUs." Llama 3 made FSDP the outermost dimension "because it can tolerate longer network latency."

Rank order enforces the rules. Megatron Core's initialize_model_parallel defaults to order="tp-cp-ep-dp-pp", with TP on adjacent ranks; Megatron-LM's training entry point switches to tp-cp-ep-pp-dp when --use-tp-pp-dp-mapping is set (Megatron-LM initialize.py, release core_v0.19.2, 2026-09-18). The default makes PP outermost; the alternate makes DP outermost, as in Llama 3. On a non-blocking fabric the difference is small; with an oversubscribed tier, the outermost dimension is the one that crosses it.

Rebalancing PP against DP moves bubble, memory and DP traffic, never TP traffic.

Sequence parallelism and activation memory

Sequence parallelism shards the layer-norm and dropout activations that TP alone replicates. The SP paper reports that SP plus selective activation recomputation "reduces activation memory by 5x" and, for a 530B GPT-3-style model on 2,240 A100 GPUs, achieves 54.2% MFU, "29% faster than the 42.1% we achieve using recomputation" [7]. Megatron Core says to "Always enable when using TP".

The paper's Table 2 gives activation bytes per transformer layer for its GPT-style layer:

  • TP only: sbh(10 + 24/t + 5as/(ht))
  • TP + SP: sbh(34/t + 5as/(ht))
  • TP + SP + selective recomputation: sbh(34/t)

Worked arithmetic for s = 8,192, b = 1, h = 16,384, t = 8 (our calculation): sbh = 134,217,728. With selective recomputation, TP only gives 13 x sbh = 1.745 GB per layer; TP + SP gives 4.25 x sbh = 0.570 GB per layer, a 3.06x reduction from SP alone. Under 1F1B the first stage holds p microbatches of L/p layers, roughly L layers' worth (the paper's Equation 5): about 126 x 0.570 = 71.8 GB for a 126-layer model, before model state, and more with interleaving. The coefficient assumes a 4h GeLU MLP and multi-head attention, so treat it as an order of magnitude for SwiGLU/GQA models. At TP = 8, SP is what lets layouts with fewer pipeline stages fit. Size the memory side with the training memory calculator.

Interleaved pipeline schedule

With 1F1B and periodic flushes, the bubble fraction is (p-1)/m. The interleaved schedule assigns v non-contiguous chunks of layers per device and reduces the bubble to (1/v) x (p-1)/m, but "the amount of communication also increases by v" [5]. The paper reports interleaving "can improve throughput by 10+%", but "without the scatter/gather optimization, the default schedule performs better than the interleaved schedule at larger batch sizes"; scatter/gather alone gave "up to 11% in throughput for communication-intensive schedules."

Interleaving trades IB bytes for bubble time, which pays when PP traffic is small relative to NIC capacity, as the worked example shows. Llama 3 used it, with bubble (PP-1)/(V x M). The paper's interleaved schedule requires the number of microbatches to be an integer multiple of the pipeline degree; Llama 3 modified its schedule to remove that constraint.

Case: 8-GPU HGX node

On an 8-GPU H100 node the rules collapse to a short list:

  • t = 8 inside the node. At fixed GPU count, per-GPU TP volume scales with t - 1, so t = 4 cuts TP traffic by 57% (3/7 of the t = 8 volume; 1,623 GB versus 3,788 GB per step in the worked example below), but it doubles parameter memory per GPU or forces more pipeline stages.
  • One NIC per GPU, 400 Gb/s. With t = 8 and scatter/gather, every PP transfer uses all eight NICs, one per rail. Rail alignment matters: NCCL's NCCL_CROSS_NIC=0 will "Always use the same NIC for the same ring/tree, to avoid crossing network rails"; the default (2) prefers the same NIC but allows crossing [9].
  • Head divisibility. Megatron's attention divides query heads and KV groups by the TP size with an exact divide() (Megatron-LM attention.py, core_v0.19.2); a model with 8 KV heads maps cleanly to t = 8.

Llama 3 405B, trained "on up to 16K H100 GPUs" in 8-GPU servers, kept TP = 8 throughout. Its Table 4: 8,192 GPUs at TP 8, CP 1, PP 16, DP 64 (430 TFLOPs/GPU, 43% BF16 MFU); 16,384 GPUs at TP 8, CP 1, PP 16, DP 128 (400, 41%); and 16,384 GPUs at TP 8, CP 16, PP 16, DP 8 for 131,072-token sequences (380, 38%) [6]. The long-context stage put CP = 16 outside the node because TP filled the NVLink domain.

Case: NVL72 domain

A 72-GPU NVLink domain lets more than one dimension live on NVLink:

  • TP > 8 without crossing the NIC. Useful for very wide layers or inference, but the TP traffic identity still applies: going from t = 8 to t = 16 raises per-GPU TP bytes by 15/7 = 2.14x at fixed n (our arithmetic), and GEMMs shrink. Bandwidth no longer forbids it; efficiency still argues against it.
  • TP x PP inside the rack. For 126 layers, 72 = 8 x 9 and 126 = 9 x 14, so TP 8 x PP 9 fits a full replica in one rack; only DP crosses IB.
  • TP x EP or TP x CP inside the rack for MoE or long-context models.

The factor of 9 is the catch. Layer counts, head counts and global batch size must divide cleanly, and most models are built around powers of two; 128 heads cannot be split 72 ways, so "one giant GPU" does not mean TP = 72. Check divisibility before committing to rack counts.

Figure 01
What fits inside the NVLink domain
8-GPU H100 node
  • Keep TP inside the node; with scatter/gather, pipeline transfers use all eight NICs, one per rail.
  • In the long-context Llama 3 stage, TP filled the NVLink domain and CP ran outside the node.
72-GPU NVLink domain
  • For the article's layer count, TP 8 x PP 9 fits a full replica in one rack; only DP crosses IB.
  • TP can share the rack with EP for MoE or CP for long-context models.

Layer counts, head counts and global batch size must divide cleanly. Check divisibility before committing to rack counts.

Worked example: 405B-class dense model on 1,024 H100 GPUs

Model shape from Llama 3 405B: 126 layers, model dimension 16,384, 128 attention heads, 8 KV heads [6], so head dimension 16,384/128 = 128 and h_kv = 8 x 128 = 1,024. Assumptions: 128 HGX H100 nodes, s = 8,192, b = 1, global batch 16M tokens = 2,048 sequences (the Llama 3 batch), BF16 activations, distributed optimizer at 6 + 12/d bytes per parameter for BF16 parameters with FP32 gradients [8]. Candidate B is the Megatron Core guide's published layout for LLaMA-3.1 405B on 1,024 GPUs: TP 8, PP 8, CP 2 [10].

Intermediate numbers: bsh x 2 bytes = 268.4 MB; TP volume per layer per microbatch at t = 8 is 7 x 268.4 MB = 1.879 GB; with p x d = 128, per-GPU TP traffic is 126 x 2,048 x 8,192 x 16,384 x (7/8) x 16 / 128 = 3,788 GB per step for every t = 8 layout.

Layout (TP, PP, CP, DP)mParams/GPUModel state GB/GPUTP GB (NVLink)PP GB (IB)CP GBDP GB (IB)Bubble (v=1)
A: 8, 16, 1, 82563.16B23.73,78817.2016.65.9%
B: 8, 8, 2, 82566.33B47.53,7888.616.9 (IB)33.22.7%
C: 16, 8, 1, 82563.16B23.78,117 (crosses IB)8.6016.62.7%
D: 8, 32, 1, 45121.58B14.23,78834.407.16.1%
E: 4, 16, 1, 161286.33B42.71,62317.2035.611.7%

Volumes are per GPU per step (our arithmetic); model state excludes activations. For A, 126 layers over 16 stages is 7.875; Llama 3 removed one layer each from the first and last stages, leaving 8 layers on the middle stages.

For scale, using 6 x P x tokens, one step is 6 x 405e9 x 16.78e6 = 4.08e19 FLOP. At Llama 3's reported 400 TFLOPs per GPU on 1,024 GPUs that is about 99.5 s per step. Then, at line rate:

  • A's TP traffic on NVLink: 3,788 GB / 450 GB/s = 8.4 s, about 8% of the step, partly overlappable.
  • The same TP traffic forced onto the NIC: 3,788 / 50 = 75.8 s, about 76% of the step.
  • C's TP16 group spans two nodes, so its ring is bounded by the per-GPU NIC: 8,117 / 50 = 162 s, longer than the entire compute time. On an NVL72 at 900 GB/s per direction, the same group would take about 9.0 s.
  • A's PP traffic over IB: 17.2 / 50 = 0.34 s (0.69 s with v = 2, which halves the bubble to 2.9%).
  • A's DP traffic: 16.6 / 50 = 0.33 s, largely overlapped with backward.

C is eliminated by bandwidth. E cuts TP traffic by 57% but pays an 11.7% bubble and 1.8x the model state of A. D minimizes memory with the deepest pipeline. A (with v = 2) and B are the serious candidates: A carries more activation memory on its first stage, while B halves per-GPU activations through CP but doubles model state and puts a per-layer CP exchange on IB. Measured memory headroom and whether the CP gather is hidden decide between them; both appear in published recipes. Apart from C's TP traffic, every IB-crossing volume here is under 1% of what a 50 GB/s NIC moves in a 100 s step (5,000 GB): once TP stays on NVLink, the fabric question is latency and placement, not raw bandwidth.

On a GB200 NVL72 system the same model maps as TP 8 x PP 9 per rack. With 14 racks (1,008 GPUs, a global batch of 2,016 sequences for divisibility), each GPU holds 405e9 / 72 = 5.63B parameters, or 5.63B x (6 + 12/14) = 38.6 GB of model state, against 186 GB of HBM3E per GPU (372 GB per two-GPU superchip). PP traffic moves onto NVLink, and the only IB traffic is DP: 5.63e9 x 13/14 x 6 = 31.3 GB per step, about 0.63 s at 400G.

Figure 02
Worked-example TP transfer time at line rateseconds per GPU per step
Source: our arithmetic

Verifying with NCCL tests and topology

  1. Topology as NCCL sees it. NCCL_TOPO_DUMP_FILE dumps "the topology as seen by NCCL"; NCCL_DEBUG=INFO with NCCL_DEBUG_SUBSYS shows ring and tree construction [9]. Confirm each GPU's NIC and rail.
  2. Benchmark the group sizes you will use. Run all_reduce_perf at t = 8 inside a node, all_gather_perf and reduce_scatter_perf across the DP group size, and sendrecv_perf between PP neighbours. Compare busbw, not algbw: busbw for all-reduce applies a 2(n-1)/n factor and "should reflect the speed of the hardware bottleneck", so it can be compared with link peak "independently of the number of ranks used" [11].
  3. Check rank-to-node mapping. Log each rank's TP, PP and DP groups with hostnames; every TP group should resolve to one host or NVL72 rack.
  4. Profile one step. A TP all-reduce far slower than measured intra-node busbw implies is a placement bug, not a tuning problem.

Algorithm and protocol choices for these collectives are covered in NCCL algorithm selection.

Figure 03
Verify placement against topology and measured bandwidth
  1. 01Inspect NCCL topology

    Dump the topology NCCL sees, inspect ring and tree construction, and confirm each GPU's NIC and rail.

  2. 02Benchmark intended groups

    Test TP all-reduce inside a node, DP all-gather and reduce-scatter, and PP send/receive. Compare busbw with link peak.

  3. 03Check rank mapping

    Log TP, PP and DP groups with hostnames. Each TP group should resolve to one host or NVL72 rack.

  4. 04Profile a training step

    Compare TP all-reduce time with measured intra-node busbw; a much slower collective indicates a placement bug.

Common mistakes

  • TP across nodes. From t larger than GPUs per node, or a launcher that does not assign contiguous ranks per host: a 9x slower link (H100, 400G NICs, per direction) carrying the largest volume.
  • Rail mismatch. Flows leaving on NIC i and arriving on NIC j cross the spine needlessly; check NCCL_CROSS_NIC and cabling against the rail plan.
  • Wrong dimension on the oversubscribed tier. Llama 3's RoCE cluster had full bisection inside 3,072-GPU pods and a 1:7 oversubscription ratio at the aggregation layer, with parallelism and scheduling "optimized to be aware of network topology, aiming to minimize network communication across pods" [6]. Only the outermost dimension should cross such a tier, and the rank order decides which one that is.
  • Treating NVL72 as TP = 72. Use the domain for TP x PP, TP x EP or TP x CP instead.
  • Skipping SP. At t = 8, TP-only activations are about 3x TP + SP for the paper's layer shape.

GPU Smith can review a proposed parallel layout against a specific node, rack and fabric design.

Sources

  1. Narayanan et al., Megatron-LM at scale, arXiv 2104.04473 (2021). https://arxiv.org/abs/2104.04473
  2. Korthikanti et al., Reducing Activation Recomputation, arXiv 2205.05198 (2022). https://arxiv.org/abs/2205.05198
  3. Meta, The Llama 3 Herd of Models, arXiv 2407.21783 (2024). https://arxiv.org/abs/2407.21783
  4. NVIDIA, Megatron Core parallelism guide (accessed 2026-10-28). https://docs.nvidia.com/megatron-core/developer-guide/latest/user-guide/parallelism-guide.html
  5. NVIDIA, Megatron Core distributed optimizer (accessed 2026-10-28). https://docs.nvidia.com/megatron-core/developer-guide/latest/user-guide/features/dist_optimizer.html
  6. Megatron-LM initialize.py, release core_v0.19.2 (2026-09-18; accessed 2026-10-28). https://github.com/NVIDIA/Megatron-LM/blob/core_v0.19.2/megatron/training/initialize.py
  7. Megatron-LM attention.py, release core_v0.19.2 (accessed 2026-10-28). https://github.com/NVIDIA/Megatron-LM/blob/core_v0.19.2/megatron/core/transformer/attention.py
  8. NVIDIA DGX H100/H200 user guide. https://docs.nvidia.com/dgx/dgxh100-user-guide/introduction-to-dgxh100.html
  9. NVIDIA, Hopper Architecture In-Depth. https://developer.nvidia.com/blog/nvidia-hopper-architecture-in-depth/
  10. NVIDIA NVLink (preliminary specs, accessed 2026-10-28). https://www.nvidia.com/en-us/data-center/nvlink/
  11. NVIDIA GB200 NVL72 (accessed 2026-10-28). https://www.nvidia.com/en-us/data-center/gb200-nvl72/
  12. NVIDIA DGX GB rack-scale user guide, Hardware. https://docs.nvidia.com/dgx/dgxgb200-user-guide/hardware.html
  13. nccl-tests PERFORMANCE.md. https://github.com/NVIDIA/nccl-tests/blob/master/doc/PERFORMANCE.md
  14. NCCL environment variables. https://docs.nvidia.com/deeplearning/nccl/user-guide/docs/env.html
