NVIDIA Open vs Proprietary Kernel Modules: Fleet Rules

Two flavors of the same driver

The NVIDIA Linux GPU driver ships five kernel modules (nvidia.ko, nvidia-modeset.ko, nvidia-uvm.ko, nvidia-drm.ko and nvidia-peermem.ko), and each driver release provides them in two flavors: an open, source-published flavor dual licensed MIT/GPLv2, and the proprietary flavor NVIDIA has historically shipped ^[1]. The two are built from the same underlying source, are mutually exclusive in the running kernel, and should not be installed on the filesystem at the same time. User space (CUDA driver library, nvidia-smi, NVML) is the same with either flavor ^[1].

For a fleet the flavor is a per-node-class decision: it determines whether Blackwell GPUs initialize at all, whether GPUDirect Storage and DMA-BUF RDMA work, and which packages a repository resolves. It sits one layer below the CUDA driver/toolkit compatibility matrix.

Architecture support by flavor and branch

The support rules have moved twice, and the README text differs between branches. The R580 README states that "the proprietary flavor supports the GPU architectures Maxwell, Pascal, Volta, Turing, and later GPUs until Blackwell," and that Blackwell and later are supported only by the open modules ^[2]. The 615.78.08 README narrows the proprietary list to "Turing, Ampere, Ada, and Hopper," again with Blackwell and later open-only ^[1]. The change reflects the end of pre-Turing support: NVIDIA's data-center architecture matrix lists R580 as the last driver branch for Maxwell, Pascal and Volta, with CUDA 12.x as their last toolkit ^[3].

The open modules "can be used on any Turing or later GPU" ^[4]. NVIDIA's July 2024 announcement added that Grace Hopper and Blackwell platforms must use the open modules, that Turing, Ampere, Ada Lovelace and Hopper users are recommended to switch, and that the open modules are not compatible with Maxwell, Pascal or Volta ^[5].

Table 1. Kernel module flavor by GPU architecture (as documented on 2026-10-28)

Sources: R580 and R615 READMEs, the 2024 NVIDIA blog and the architecture matrix cited above. "Last driver branch" is from the matrix; R580 is a Long Term Support Branch with end of life in June 2028, per NVIDIA's supported drivers page (revision of Sep 09, 2026).

A fleet with V100 and B200 nodes therefore cannot run one driver build everywhere: the V100 pool is capped at R580 proprietary, the B200 pool needs the open flavor.

Features that only work with the open flavor

Both the R580 and R615 READMEs list the same five features that work only with the open kernel modules ^[1]:

Table 2. Open-only features and why a fleet cares

The right-hand column is a plain-language reading of each feature name, not NVIDIA wording. Two of these items reach well beyond the GPU itself. NVIDIA's GPU Operator documentation states that its GDS driver, version 2.17.5 or newer, "is only supported with the NVIDIA Open GPU Kernel module driver," and that the DMA-BUF path for GPUDirect RDMA requires an open kernel module driver, while the legacy nvidia-peermem path works with any supported driver but requires MLNX_OFED or DOCA-OFED ^[6]. NVIDIA recommends DMA-BUF over nvidia-peermem on that same page. A cluster that wants GDS-backed checkpointing or the recommended RDMA path is therefore on the open flavor whether or not it has Blackwell GPUs; the storage-side prerequisites are in the GPUDirect Storage readiness matrix.

Known costs of the open flavor

The README is explicit that the open modules are not free of trade-offs. Compared with the proprietary modules running with GSP firmware disabled, it lists four known issues ^[1]:

• GPU initialization is slower; NVIDIA suggests running nvidia-persistenced so GPUs are initialized before applications start.
• Entry and exit latency for S3, S4 and Runtime D3 power states can be longer, because additional GSP state is restored.
• GPU power consumption "can be marginally impacted in some scenarios."
• Turing GPUs support only the Video Memory Off flavor of Runtime D3.

On servers the first item matters most: without nvidia-persistenced, cold starts and health checks pay the initialization cost. On performance, the only published statement is NVIDIA's 2024 claim of "equivalent or better application performance," with no figures attached ^[5]; the switch deserves its own acceptance run.

Licensing, source and GSP firmware

The open modules are dual licensed MIT/GPLv2, and the source for every driver release is published at NVIDIA/open-gpu-kernel-modules with a tarball on download.nvidia.com ^[7]. As of 2026-10-28 the GitHub README describes version 615.78.08 and lists three constraints that matter for anyone building modules themselves ^[4]:

1. The modules "must be used with GSP firmware and user-space NVIDIA GPU driver components from a corresponding 615.78.08 driver release." Kernel modules and user space are version-locked to the same release.
2. The supported kernel floor is Linux 4.15 or newer.
3. The kernel interface layer must be built with the toolchain that was used to build the kernel.

The open modules are not a full open-source driver: device initialization and management are offloaded to the GPU System Processor (GSP), driven by firmware files that ship with the driver as gsp_*.bin under /lib/firmware/nvidia/<version>/. GSP firmware is used by default on all Turing and later GPUs and can be disabled only with the module parameter NVreg_EnableGpuFirmware=0 ^[8]. Because the open modules require GSP, "GSP off" is a proprietary-only configuration, and image builders must ship the matching /lib/firmware/nvidia/ tree with the modules.

Packaging: from R560 to R615

Three changes in NVIDIA's packaging explain why fleets that never chose a flavor now find themselves on one.

R560 (2024): the default flips. NVIDIA announced that from R560, installs through package managers, the runfile and the CUDA metapackage default to the open modules, with the cuda metapackage pairing the open driver from CUDA 12.6 onward ^[5].

R570 and later: unified package names. The installation guide states that "all releases beyond driver version 570 will use these packaging conventions," with nvidia-open as the install target on every listed distribution (for example dnf install nvidia-open on RHEL 10, apt install nvidia-open on Debian and Ubuntu, zypper install nvidia-open on SUSE) and branch pinning through DNF module streams, nvidia-driver-pinning-<branch> on apt, or zypper addlock ^[7]. The R610 edition of the guide still documents cuda-drivers as the meta package that "installs all NVIDIA proprietary kernel modules Driver packages," and gives per-distribution commands to switch flavors, for example apt install --autoremove --purge cuda-drivers nvidia-driver to go from open to proprietary on Ubuntu ^[9].

R615: the proprietary packages disappear from the repository path. The R615 edition of the same page lists only nvidia-open in its kernel module meta-package table and has no flavor-switching section ^[10]. NVIDIA's CUDA apt repository for Ubuntu 24.04 shows the same change in its package metadata (CUDA repo Packages index, ubuntu2404/x86_64, read 2026-10-28):

Table 3. What the proprietary-named packages resolve to (ubuntu2404 CUDA repo)

On that repository, automation that installs cuda-drivers to get the proprietary flavor gets the open flavor once it resolves an R615 version. The runfile still offers a choice: the 615.78.08 README says installation defaults to open and that --kernel-module-type (short form -M) with proprietary or open overrides it ^[1]. The README's own example shows -m=kernel-open, an older form that does not match its prose; scripts should use the long --kernel-module-type= option and check the result rather than trust either spelling. NVIDIA's RHEL 9 and SLES 15 x86_64 repositories go further: R615 ships only kmod-nvidia-open-dkms (DNF stream 615-open, no 615-dkms) or nvidia-open-driver-G07, with no proprietary kernel package and no 615 cuda-drivers (repository metadata read 2026-10-28).

R615 is a New Feature Branch: NVIDIA's data-center driver index lists it as "new feature branch", with 615.71.09 (2026-09-09) and 615.71.10 (2026-10-19) (releases.json). The supported-drivers page (Sep 09, 2026) does not list it yet; R580 (Long Term Support Branch, to June 2028) and R595 (Production Branch, to March 2027) are the conservative choices.

Verifying which flavor is loaded

The README gives two checks ^[1]:

# modinfo nvidia | grep license
license:        Dual MIT/GPL          # open flavor ("NVIDIA" = proprietary)

# cat /proc/driver/nvidia/version
NVRM version: NVIDIA UNIX Open Kernel Module for x86_64  [...]

The proprietary flavor reports NVIDIA UNIX x86_64 Kernel Module without the word "Open." modinfo reads the module file on disk for the running kernel, while /proc/driver/nvidia/version reflects the module actually loaded; after a package swap without a reboot or module reload the two can disagree, and the /proc value is the one that counts. A third check confirms GSP: nvidia-smi -q shows a GSP Firmware Version when GSP is active and "N/A" when disabled ^[8].

A minimal per-node collector for the fleet inventory:

#!/usr/bin/env bash
# Prints: host, loaded flavor, driver version, GPU model, GSP firmware
flavor=$(grep -q 'Open Kernel Module' /proc/driver/nvidia/version && echo open || echo proprietary)
drv=$(nvidia-smi --query-gpu=driver_version --format=csv,noheader | head -1)
gpu=$(nvidia-smi --query-gpu=name --format=csv,noheader | head -1)
gsp=$(nvidia-smi -q | awk -F': ' '/GSP Firmware Version/{print $2; exit}')
echo "$(hostname),$flavor,$drv,$gpu,$gsp"

Alert on any node whose flavor differs from its node-class policy (Table 1).

Kubernetes: the GPU Operator setting

In the NVIDIA GPU Operator, the flavor is chosen with driver.kernelModuleType, whose valid values are auto (default), proprietary and open; auto picks the recommended type "based on the GPU devices on the host and the driver branch used." The older boolean driver.useOpenKernelModules is deprecated as of v25.3.0 and ignored (GPU Operator: Getting Started, documentation for patch release v26.7.2). For GDS and DMA-BUF, NVIDIA advises adding --set driver.kernelModuleType=open when using a driver from a branch earlier than R570, and setting it explicitly to be sure the open module is used ^[6].

In a mixed cluster auto makes the flavor an implicit function of hardware and branch; set it explicitly per node pool and review it at each Operator upgrade.

Migrating a mixed fleet

A migration plan follows from Tables 1 to 3. An illustrative fleet makes the structure concrete (node counts are hypothetical):

Table 4. Illustrative node-class plan

Of 160 nodes, 32 are already forced onto open, 16 cannot migrate, and only the 112 elective nodes (48 + 64) carry migration risk and need a canary.

A per-class sequence that respects the documented constraints:

1. Freeze the target. Choose the branch and record the flavor per node class. Use branch pinning (nvidia-driver-pinning-<branch>, DNF streams such as nvidia-driver:580-open, or zypper addlock) as documented in the installation guide, so that an unpinned R615 resolution cannot change a node's flavor silently.
2. Remove, then install. The flavors must not coexist on disk ^[1], so use the distribution's documented switch command (purge-and-install on apt, --allowerasing on dnf) rather than layering packages.
3. Reboot and verify. Confirm /proc/driver/nvidia/version, the GSP firmware version and the driver version with the collector above, then run the node's normal acceptance suite (NCCL, GDS and DCGM diagnostics) before returning it to the scheduler.
4. Keep a rollback artifact. For R610 and earlier, rollback to proprietary is a documented package switch. For R615 on repositories where proprietary names are transitional (Table 3), rollback means pinning back to an earlier branch or using the runfile with --kernel-module-type=proprietary; this must be decided before the upgrade, not during an incident. Pre-flight gating of the same change is described in the CUDA production upgrade gate.

Pitfalls

Secure Boot and module signing. Canonical's Ubuntu documentation recommends ubuntu-drivers on Secure Boot systems because it installs pre-built, signed modules; it does not recommend DKMS modules unless a custom kernel requires them, because DKMS builds "are not signed with Canonical's key and thus do not support secure boot" ^[11]. Ubuntu ships open variants of its server drivers (for example nvidia-driver-535-server-open, on the same page), so the signed path is available for the open flavor too. NVIDIA's own repository installs nvidia-dkms-open, which builds locally and needs an enrolled signing key under Secure Boot.

Source builds. Install the .run user space with --no-kernel-modules, then build same-version source with the kernel's toolchain ^[1][4].

Pre-Turing nodes on new branches. A V100 node that resolves a branch later than R580 has no supported driver at all ^[3], so branch pins on legacy pools are mandatory.

Pre-flight checklist

Table 5. Flavor change pre-flight

GPU Smith can review a fleet's driver and kernel-module plan against these documented constraints as part of an upgrade engagement.

Sources

1. Chapter 44. Open Linux Kernel Modules, NVIDIA driver README 615.78.08 - NVIDIA; flavors, R615 architecture support, open-only features, known issues, installer options, verification (accessed 2026-10-28)
2. Chapter 43. GSP Firmware, NVIDIA driver README 615.78.08 - NVIDIA; GSP default on Turing+, firmware path, NVreg_EnableGpuFirmware, nvidia-smi -q check (accessed 2026-10-28)
3. Open Linux Kernel Modules, NVIDIA driver README 580.65.06 - NVIDIA; R580 architecture support wording (accessed 2026-10-28)
4. NVIDIA/open-gpu-kernel-modules (GitHub README) - NVIDIA; version 615.78.08, Turing+ support, GSP and user-space version lock, kernel 4.15+, toolchain rule (accessed 2026-10-28)
5. NVIDIA Transitions Fully Towards Open-Source GPU Kernel Modules - NVIDIA Technical Blog, Jul 17, 2024; R560 default, Grace Hopper/Blackwell requirement, pre-Turing incompatibility, performance claim (accessed 2026-10-28)
6. CUDA Toolkit, Driver and Architecture Matrix - NVIDIA, updated Sep 09, 2026; R580 last branch for Maxwell, Pascal, Volta (accessed 2026-10-28)
7. Supported Drivers and CUDA Toolkit Versions - NVIDIA, updated Sep 09, 2026; branch designations and end-of-life dates (accessed 2026-10-28); release index with R615 branch type: https://docs.nvidia.com/datacenter/tesla/drivers/releases.json
8. Driver Installation Guide: Kernel Modules - NVIDIA, updated Sep 23, 2026; MIT/GPLv2 licensing, post-570 packaging, install and pinning commands (accessed 2026-10-28)
9. Driver Installation Guide 610: Advanced Options - NVIDIA; cuda-drivers proprietary meta package, flavor-switching commands (accessed 2026-10-28)
10. Driver Installation Guide 615: Advanced Options - NVIDIA; R615 meta-package table listing only nvidia-open (accessed 2026-10-28)
11. CUDA repository Packages index, ubuntu2404/x86_64 - NVIDIA; package dependencies for 610.57.04 and 615.71.10 (read 2026-10-28); RHEL 9 and SLES 15 repodata: https://developer.download.nvidia.com/compute/cuda/repos/rhel9/x86_64/repodata/repomd.xml and https://developer.download.nvidia.com/compute/cuda/repos/sles15/x86_64/repodata/repomd.xml
12. GPU Operator: Getting Started - NVIDIA, v26.7.2 docs; driver.kernelModuleType values and default, useOpenKernelModules deprecation (accessed 2026-10-28)
13. GPU Operator: GPUDirect RDMA and GPUDirect Storage - NVIDIA; GDS 2.17.5+ open-only, DMA-BUF prerequisites, pre-R570 guidance (accessed 2026-10-28)
14. NVIDIA drivers installation, Ubuntu Server documentation - Canonical; signed pre-built modules, DKMS and Secure Boot, -server-open packages (accessed 2026-10-28)
