OpenAI-Compatible Gateways for Private LLM Clusters

Why a private inference cluster needs a gateway

A self-hosted model server such as vLLM already speaks an OpenAI-style HTTP API, so the first internal consumer can point an unmodified OpenAI client at it. The trouble starts with the second consumer: the server has no notion of tenants, budgets, per-team model allow-lists or a hosted-provider fallback, and its built-in authentication is a shared static key. Once several teams share a GPU pool, the operator needs a front door that decides per request who is calling, which models they may use, how much capacity they may consume, and which replica or provider serves them.

This guide separates two tiers that are often conflated. The API tier handles OpenAI compatibility, identity, quotas, spend attribution and cross-provider failover. The endpoint-picking tier decides which model-server pod inside a pool receives the request, using model-server signals such as queue length, KV-cache state and prefix-cache locality. LiteLLM-style proxies live mostly in the first tier, the Kubernetes Gateway API Inference Extension in the second, and Envoy-based AI gateways can span both. Routing economics are covered in the small vs large model routing cost model; this article covers the plumbing that makes a routing policy enforceable.

What the model servers already provide

The vLLM OpenAI-compatible server exposes, among others, /v1/completions, /v1/chat/completions, /v1/responses, /v1/embeddings, /v1/audio/transcriptions and /v1/audio/translations, plus an Anthropic-style /v1/messages, Cohere-style rerank and embed routes, /v1/models, /health and /metrics (vLLM docs: Online serving; all present in the v0.32.0 source, released 2026-10-18). A gateway in front of vLLM therefore rarely needs to translate formats for self-hosted models, only to pass them through and account for them.

Authentication is the weak point. In v0.32.0 the --api-key flag (or VLLM_API_KEY) only authenticates paths under /v1, /v2, /inference and /cohere ^[1]; other endpoints, including unprefixed /rerank and /score and "most notably /invocations", are not authenticated, and the documentation states: "Do not rely on --api-key alone to secure vLLM" ^[2]. Model-server pods should therefore be reachable only from the gateway (network policy, mesh authorization or a private subnet).

vLLM also exports the signals both tiers need, such as vllm:time_to_first_token_seconds, vllm:inter_token_latency_seconds, vllm:num_requests_running and vllm:kv_cache_usage_perc ^[3]. What it does not provide is anything keyed to a tenant.

Table 1. Responsibility split between model server and gateway tiers

Pattern 1: LiteLLM-style proxy

LiteLLM Proxy describes itself as "one OpenAI-compatible endpoint for 100+ LLM providers, MCP tools, and A2A agents"; existing OpenAI clients switch by changing the base URL ^[4]. A self-hosted vLLM server is registered with the hosted_vllm/<model-name> prefix and an api_base; the older vllm/ prefix is deprecated ^[5]. The client-facing alias (model_name) is decoupled from the backend, so a checkpoint can be swapped without touching clients.

Tenancy is built on virtual keys: "Give each user, team, and project a virtual key", each carrying its own models, budgets and rate limits, with spend visible by key, team, user and tag ^[4]. Virtual keys require a Postgres database (DATABASE_URL) and a master key beginning with sk-; keys are minted via POST /key/generate, restricted with a models list, and rotated via /key/<key>/regenerate with an optional grace_period such as "48h" ^[6].

Per the budgets page fetched 2026-10-28, limits are set with tpm_limit (tokens per minute), rpm_limit (requests per minute) and max_parallel_requests at team, internal-user or key level, plus max_budget with a budget_duration reset window ^[7]. TPM counts total tokens by default; token_rate_limit_type can restrict counting to input or output tokens. Three operational details matter more than the parameter names:

• Budgets need the database. Without Postgres, budgets are not enforced.
• Counters are shared through Redis. If Redis is down, each proxy instance enforces limits independently, so three replicas turn a 100,000 TPM limit into up to 300,000 TPM (derived); fail_closed_rate_limit_enforcement: true returns 503 instead.
• Budget reservation is on by default. The proxy estimates a request's maximum cost, reserves it against the budget, and later replaces the reservation with the actual cost; disabling it lets concurrent requests overshoot.

The documented examples show 400, 401 and 429 for different budget breaches, so client retry logic should key on the error body, not a single status code.

Failover is configured per model group: fallbacks, context_window_fallbacks and content_policy_fallbacks lists, num_retries (retries happen before fallback), and allowed_fails / cooldown_time to bench a failing deployment ^[8].

The limitation is pool visibility: LiteLLM balances across deployments, each typically a Service URL, without seeing per-pod KV-cache occupancy or prefix-cache locality.

Pattern 2: Envoy-based AI gateway (Agent Router, formerly Envoy AI Gateway)

The project's README, fetched 2026-10-28, states: "Envoy AI Gateway is now Agent Router, an Agentic AI Foundation project," with the repository now at github.com/theagentrouter/agent-router and docs at theagentrouter.ai (old links redirect); CRDs, API group, aigw CLI and images keep their names ^[9][10]. The latest stable tag at the time of writing is v1.2.0, published 2026-10-07 ^[11].

The README describes a two-tier pattern: "The Tier One Gateway handles authentication, top-level routing, and global rate limiting", while "The Tier Two Gateway provides fine-grained control over self-hosted model access, with endpoint picker support for LLM inference optimization" ^[9].

Token-based limiting uses Envoy Gateway's Global Rate Limit API backed by Redis. An AIGatewayRoute declares llmRequestCosts of type InputToken, CachedInputToken, OutputToken, TotalToken or CEL (a custom expression), and a BackendTrafficPolicy sets the limits, typically keyed on a tenant header and the x-ai-eg-model header (Agent Router docs: Usage-based rate limiting, v1.2). The enforcement timing matters most: tokens are charged after the response completes (for streams, when the stream ends), and a request is rejected with 429 only if usage already charged exceeds the limit. An admitted stream is not cut off. The same page distinguishes this per-client allowance from QuotaPolicy, which caps a backend's upstream consumption for a model across all routes and consumers.

For self-hosted pools, an AIGatewayRoute rule can reference a backend with group: inference.networking.k8s.io and kind: InferencePool, routing by the model name extracted from the request body, and the documentation presents mixing InferencePool and conventional backends in one route as supported ^[12]. That makes it a single control plane for both tiers on clusters already standardized on Envoy Gateway.

Pattern 3: Gateway API Inference Extension and endpoint pickers

The Gateway API Inference Extension (GIE) is "an official Kubernetes project that optimizes self-hosting Generative Models on Kubernetes" ^[13]. It uses Envoy's ext-proc protocol to extend any gateway supporting ext-proc and Gateway API, and positions itself underneath higher-level AI gateways such as LiteLLM, Gloo AI Gateway or Apigee ^[14].

The core resource is the InferencePool, inference.networking.k8s.io/v1, GA since GIE v1.0.0. It groups pods sharing a base model, accelerator type and model server; its spec has a pod selector, targetPorts and an endpointPickerRef pointing at the Endpoint Picker (EPP) service, and the documented example sets failureMode: FailOpen so the gateway picks an endpoint itself if the EPP does not respond ^[15]. In Gateway API terms an InferencePool replaces a Service as an HTTPRoute backend.

The project's scope changed in 2026, so older tutorials are partly wrong. The v1.6.0 release (2026-08-17) moved the full-featured EPP, Body-Based Routing and the latency predictor to the llm-d organization, removed the alpha InferenceObjective, InferenceModelRewrite and EndpointPickerConfig APIs from GIE, made endpointPickerRef optional, and introduced a lightweight EPP (lwepp) intended for conformance testing ^[16]. The latest GIE release at the time of writing is v1.6.2 (2026-09-17) ^[17]. The home page still lists "serving priority"; that capability now lives in llm-d.

The production EPP is now the llm-d Router (formerly "Inference Scheduler"), which hosts the EPP, InferenceObjective and InferenceModelRewrite and runs either standalone with its own Envoy or behind a Gateway via InferencePool ^[18]. Its v1.0.0 release (2026-10-16) graduated InferenceObjective to llm-d.ai/v1 with multi-pool targeting ^[19]. The EPP filters candidate pods and scores them with weighted scorers for KV-cache locality, session affinity, load and model metadata; flow control (the admission and queueing layer) is off by default and enabled with the flowControl feature gate ^[20]. The InferenceObjective priority field is an integer where higher is more critical; under scarcity, flow control "will always allow requests of higher priority to be served first," and fairness applies only among requests of equal priority ^[21].

The implementations page lists Alibaba Cloud ACK, Istio, Agentgateway, Higress and NGINX Gateway Fabric ^[22]; the home page also names Envoy Gateway, kgateway and GKE Gateway.

Auth and tenancy design

A workable tenancy model has three layers: identity (ideally inherited from corporate SSO), entitlement (which model aliases it may call) and allowance (tokens, dollars or concurrent requests).

In LiteLLM, the simplest implementation is one team per consuming application, virtual keys per team, and a team-level models list that keys with all-team-models inherit ^[6]. For SSO mapping, JWT auth verifies tokens from an OIDC provider via JWT_PUBLIC_KEY_URL, maps user_id_jwt_field and team_id_jwt_field claims, and with enforce_team_based_model_access: true admits a request only if one of the user's groups maps to a team with access to the model; this is an Enterprise-licensed feature ^[23]. In an Envoy-based design, gateway JWT or external-authorization filters stamp a tenant header that rate-limit policies key on.

Static keys on the model servers, if used, should be gateway-to-backend credentials no human holds, and key rotation with a grace period should be rehearsed before an incident. Air-gapped deployments add their own constraints on identity providers and image provenance, discussed in the air-gapped LLM deployment guide.

Quotas: requests versus tokens

A requests-per-minute limit treats a 200-token chat turn and a 30,000-token document summarization as equal. On a GPU they are not: prefill grows with prompt length, KV-cache footprint with prompt plus output, and decode time with output.

Worked example (illustrative workloads). Two tenants each receive 60 RPM.

• Tenant A, chat: 1,500 input + 300 output = 1,800 tokens per request; 60 × 1,800 = 108,000 tokens/min.
• Tenant B, retrieval-augmented summarization: 24,000 input + 1,000 output = 25,000 tokens per request; 60 × 25,000 = 1,500,000 tokens/min.

Identical request limits allow Tenant B about 13.9× (1,500,000 ÷ 108,000) the token volume of Tenant A. A shared 200,000 tokens/min limit instead admits about 111 chat requests per minute (200,000 ÷ 1,800) but only 8 summarization requests (200,000 ÷ 25,000, rounded down), which tracks GPU work far better.

Total tokens still under-weight output if decode is the scarce resource. A weighted cost (an Agent Router CEL cost) can encode that. With an illustrative weight of 4 per output token: Tenant A costs 1,500 + 4 × 300 = 2,700 units; Tenant B costs 24,000 + 4 × 1,000 = 28,000 units, a ratio of about 10.4× rather than 13.9×. A real weight must come from measured prefill and decode cost.

Overshoot from post-hoc charging (derived). Because Agent Router charges tokens after completion and rejects only once charged usage exceeds the limit, worst-case overshoot is roughly the requests admitted while under the limit times their maximum size. If a tenant has 10 concurrent streams in flight when it crosses a 100,000-token hourly limit, each with an 8,000-token prompt and max_tokens of 4,096, the window can close at up to 100,000 + 10 × 12,096 = 220,960 tokens, about 2.2× the nominal limit. The remedies are a concurrency cap per tenant and a server-side ceiling on max_tokens. LiteLLM's budget reservation addresses the same problem for dollar budgets.

Concurrency and priority. Token limits govern volume; max_parallel_requests (LiteLLM) or a per-tenant concurrency limit governs instantaneous pressure on KV cache. By Little's law, Tenant B at 8 requests/min (0.133 req/s) with an illustrative 20-second latency holds about 2.7 requests in flight. Priority belongs in the endpoint-picking tier, where llm-d flow control can serve interactive traffic ahead of batch traffic once the pool saturates.

Table 2. Limit types and where to enforce them

Routing and failover

Routing happens at three levels: across providers (private pool versus hosted endpoints), across pools (model alias to InferencePool or Service), and within a pool (the EPP selects the pod). Cache-aware picking matters most for long shared prefixes such as system prompts, where a pod already holding the prefix skips recomputing prefill; the llm-d EPP includes prefix-cache scoring ^[20].

Two failure modes need explicit decisions. On EPP failure, FailOpen keeps traffic flowing with degraded placement, while fail-closed protects SLOs at the cost of availability. Hosted-provider fallback is a data-governance decision as much as a reliability one and should be set per model alias, so regulated workloads never leave the perimeter.

Observability and chargeback

LiteLLM records the cost of each request and reports spend by key, team, user and tag, exporting to Prometheus, OpenTelemetry and other sinks ^[4]. Self-hosted models need an internal price, set as input_cost_per_token and output_cost_per_token under model_info. Setting both to 0 makes the model free and lets it bypass budget checks, while leaving them null keeps the model billable ^[24]. An operator who wants budgets enforced on private models therefore needs a non-zero internal rate.

Worked chargeback (illustrative rates). Assume an internal transfer price of $0.20 per million input tokens and $0.80 per million output tokens, configured as input_cost_per_token: 0.0000002 and output_cost_per_token: 0.0000008. Tenant B sends 200,000 requests in a month: 200,000 × 24,000 = 4.8 billion input tokens × $0.20/M = $960; 200,000 × 1,000 = 0.2 billion output tokens × $0.80/M = $160; total $1,120. Real rates should come from the cluster's fully loaded cost per token.

Latency SLOs come from vLLM's histograms (TTFT, inter-token latency, end-to-end latency) joined to tenant labels from gateway logs. The definitions and pitfalls of those metrics are covered in inference SLO metrics: TTFT, ITL, TPS and goodput. Gateway-measured latency includes gateway and EPP queueing and should be reported alongside server-side numbers.

Decision matrix and rollout

Table 3. Choosing a pattern (qualitative)

A low-risk rollout sequence is: (1) lock the model servers behind network policy so the gateway is the only path; (2) introduce the API tier with model aliases, per-team keys and request limits only, in observe mode where available; (3) add token limits and concurrency caps sized from observed token distributions; (4) replace Services with InferencePools and an EPP for pools with heavy prefix reuse, starting fail-open; (5) enable priority and flow control once interactive and batch traffic are labeled. The vLLM KV cache capacity planner gives concurrency caps a defensible basis.

The versions referenced here (Agent Router v1.2.0, GIE v1.6.2, llm-d Router v1.0.0, LiteLLM v1.106.6 of 2026-10-28) are recent and changing quickly; configuration field names should be rechecked against the release in use. GPU Smith can review a proposed gateway design against a specific cluster's tenancy and SLO requirements.
