Private RAG Hardware Sizing: Embeddings, Reranker, Index

The short answer

In a private RAG deployment the retrieval components are usually smaller than the generator LLM, but they do not size themselves. Three numbers decide the hardware: the vector index footprint (vectors x dimensions x bytes per value, plus a graph overhead you can compute from your vector database's own documentation), the ingestion compute (corpus tokens x embedding-model FLOPs per token), and the reranker compute per query (candidates x tokens per candidate x reranker FLOPs per token). For a 10-million-chunk corpus with 1024-dimension fp32 embeddings, the index alone needs roughly 43 to 52 GB of RAM depending on the database, while a cross-encoder reranker scoring 50 candidates per query costs on the order of 800 times more compute than embedding the query.

Below: worked arithmetic from official docs and model cards, CPU HNSW vs GPU CAGRA, and a measurement protocol, since no published throughput figure will match your chunk lengths and recall target. For the generator, see our LLM inference hardware sizing guide.

RAG pipeline workload anatomy

Two workloads share the same components:

The embedding model is cheap at query time and expensive at ingestion; the reranker runs only on the query path and is usually its most expensive retrieval step; the index is memory-bound on both. Our batch vs real-time sizing article covers the same split for the generator.

Embedding serving

Hugging Face Text Embeddings Inference (TEI) serves open embedding and reranker models. Its docs list token-based dynamic batching, optimized inference via Flash Attention, Candle and cuBLASLt, Safetensors weight loading, no model graph compilation step, and Prometheus metrics plus OpenTelemetry tracing ^[1]. The README covers rerankers (single-class sequence-classification cross-encoders) and an air-gapped path: download weights, then mount them into the container ^[2].

The README for TEI v1.9.4 (released 2026-09-15) publishes 1.9 images for CPU (x86 and arm64), Turing (experimental), Ampere, Ada Lovelace, Hopper and, experimentally, Blackwell. The sizing-relevant flags (defaults verified in the v1.9.4 source) are:

• --max-batch-tokens (default 16384): total tokens in one batch, described as "one critical control to allow maximum usage of the available hardware".
• --max-client-batch-size (default 32): maximum inputs a client can send in one request.
• --max-concurrent-requests (default 512): requests beyond this are refused, not queued.

Because batching is by tokens, plan in tokens per second, not requests per second: a 512-token chunk costs roughly 16 times a 32-token query. Measure it with your real chunk-length distribution via TEI's Prometheus metrics.

Choosing an embedding model: quality, dimension, memory

MTEB is the standard reference for comparing models. The original paper covers 8 embedding tasks, 58 datasets and 112 languages, benchmarked 33 models and found that "no particular text embedding method dominates across all tasks" ^[3]. Shortlist on the retrieval subsets in your languages, then validate on your own documents.

Two properties matter for hardware: parameter count (GPU memory, FLOPs) and output dimension (index memory). From model cards and Hugging Face file metadata, October 2026:

Sources: bge-base-en-v1.5 card, bge-m3 card, bge-reranker-v2-m3 card, Qwen3-Embedding-8B card. The bge-m3 card gives no parameter count. Its config.json (24 layers, hidden 1,024, FFN 4,096, 250,002-token vocabulary, 8,194 positions) gives 567,754,752 parameters for an XLM-RoBERTa encoder with pooler, which matches the 2,271,145,830-byte fp32 pytorch_model.bin ^[4] at 4 bytes each; the reranker's 567,755,777 swaps the pooler for a classification head. Weight memory is parameters x bytes per parameter; activations come on top and scale with --max-batch-tokens.

A BERT- or XLM-RoBERTa-large-class embedder fits on almost any data center GPU. An 8B embedder is closer to serving a small LLM, and its 4096-dimension output quadruples index memory versus 1024 unless you use its user-defined 32-4096 output dimension; check retrieval quality at the truncated size first.

Index memory math

The base term is always vectors x dimensions x bytes per value; databases differ in graph overhead and bookkeeping.

Assumptions (illustrative): 10,000,000 chunks, 1024-dimension embeddings (for example bge-m3), one vector per chunk, no replication.

Raw vectors

• fp32: 10,000,000 x 1024 x 4 B = 40,960,000,000 B = 40.96 GB
• fp16: 10,000,000 x 1024 x 2 B = 20.48 GB
• Same corpus at 4096 dimensions fp32: 163.84 GB

FAISS IndexHNSWFlat. The FAISS guidelines give memory as "(d * 4 + M * 2 * 4) bytes per vector", with M between 4 and 64 links per vector, and list HNSW as not supported on GPU ^[5]. With M = 32 (an assumption):

• Per vector: 1024 x 4 + 32 x 2 x 4 = 4096 + 256 = 4352 B
• Total: 10,000,000 x 4352 B = 43.52 GB, of which the graph is 2.56 GB

Qdrant. Qdrant's capacity-planning guide gives dense_size = base * dimensions * bytes_per_dim, hnsw_size = base * m * 2 * 4 bytes * 1.2 (the 1.2 covers lower graph layers and bookkeeping), id_tracker_size = base * 52 bytes, and recommends about 20% headroom on totals ^[6]. With m = 16 (the value in Qdrant's own example):

• Vectors: 40.96 GB
• HNSW: 10,000,000 x 16 x 2 x 4 x 1.2 = 1.536 GB
• ID tracker: 10,000,000 x 52 = 0.52 GB
• RAM before headroom: 43.02 GB; with 1.2 headroom: 51.62 GB
• Payloads (chunk text, metadata) are extra and default to disk.

pgvector. The README (v0.8.7) gives storage per value as 4 * dimensions + 8 bytes for vector, 2 * dimensions + 8 for halfvec and dimensions / 8 + 8 for bit; HNSW indexes take vector up to 2,000 dimensions and halfvec up to 4,000; HNSW defaults are m = 16 and ef_construction = 64; and builds are "significantly faster when the graph fits into maintenance_work_mem" ^[7].

• vector(1024): 4,104 B x 10M = 41.04 GB of vector data
• halfvec(1024): 2,056 B x 10M = 20.56 GB
• Binary quantized expression index on bit(1024): 136 B x 10M = 1.36 GB, with re-ranking by the original vectors recommended for recall
• These exclude row/page overhead and the HNSW index, which the README does not quantify; measure a sample load.
• A 4096-dimension vector cannot be HNSW-indexed in pgvector without truncation.

Milvus. The Milvus HNSW page states that HNSW "requires high memory overhead to maintain its hierarchical graph structure", with M defaulting to 30 and efConstruction to 360, but gives no per-vector formula (Milvus HNSW docs, v3.0.x; current release v3.0.4). Apply the FAISS-style M * 2 * 4 bytes per vector as an approximation and validate with a test load.

cuVS CAGRA (GPU). The cuVS CAGRA guide defines dataset_size (device) = N x D x B and graph_size (host) = N x G x S_idx, with defaults graph_degree = 64 and intermediate_graph_degree = 128, and 4-byte neighbour IDs ^[8]:

• Device dataset: 40.96 GB fp32 or 20.48 GB fp16
• Graph: 10,000,000 x 64 x 4 B = 2.56 GB
• The guide recommends reserving headroom H = 0.20 for IVF-PQ graph builds and H = 0.30 for NN-Descent builds, applied as M_usable = (M_free - M_other) x (1 - H).

Summary for 10M x 1024 dimensions:

At 1024 dimensions the vectors are about 94% of the footprint. Precision and dimension move the bill far more than HNSW parameters.

CPU HNSW

HNSW builds a multi-layer structure of proximity graphs, with search starting at the top layer and descending, giving logarithmic complexity scaling ^[9]. For most private RAG corpora it is enough. Sizing properties:

• RAM-bound. Qdrant advises against cold-tiering HNSW because traversal "does many small random reads that suffer badly from disk latency" ^[6].
• Build time is the CPU pain point. Higher efConstruction "leads to longer indexing time and increased memory usage during construction" ^[10]; pgvector builds use 2 parallel workers by default and slow down when the graph exceeds maintenance_work_mem ^[7].
• Query cost is modest at typical RAG QPS; a CPU server with enough RAM often serves search while GPUs embed and rerank.

GPU indexes with cuVS and CAGRA

NVIDIA cuVS is "a GPU-accelerated library for vector search", and among its stated benefits are fast index build and "Interoperability (build on GPU, deploy on CPU)" ^[11]. CAGRA is its GPU-native graph index.

The CAGRA paper reports, on the authors' hardware and datasets ^[12]:

• graph construction 2.2 to 27 times faster than HNSW;
• large-batch query throughput 33 to 77 times higher than HNSW at 90-95% recall, and 3.8 to 8.8 times higher than prior GPU implementations;
• single-query search 3.4 to 53 times faster than HNSW at 95% recall.

This is a 2023 paper (revised July 2024) comparing a GPU with a CPU baseline; the ratio depends on both devices, the dataset and the recall point.

More useful for private RAG is the hybrid mode: converting a CAGRA graph to HNSW lets "the GPU build the graph while the CPU handles search later", and the guide recommends CAGRA "when the index fits in GPU memory" ^[8]; see hnsw.from_cagra in the cuVS HNSW Python API. NVIDIA lists integrations including FAISS (GpuIndexCagra, convertible via IndexHNSWCagra), Milvus, Elasticsearch, OpenSearch and Solr ^[13]. Milvus 2.6.4+ can convert a GPU_CAGRA index into "a CPU-executable format (HNSW-like)" at load via adapt_for_cpu ^[14].

Build memory, worked. For the 10M x 1024 corpus:

• During build the dataset must be in GPU memory: 40.96 GB fp32 or 20.48 GB fp16.
• An NN-Descent initial graph peaks at N x (D x 2 + 276) B on device = 10M x 2,324 B = 23.24 GB, and N x (13 x I + 912) B on host = 10M x 2,576 B = 25.76 GB with I = 128 ^[8].
• Assumption: a GPU with 48 GB free and nothing else resident. With H = 0.20: 48 x 0.8 = 38.4 GB usable, which does not hold the fp32 dataset but does hold fp16. With 80 GB free: 64 GB usable, enough for fp32.
• Larger corpora: IVF-PQ initial-graph builds can run in batches over datasets larger than GPU memory, and cuVS ships multi-GPU CAGRA APIs.

When GPU indexing pays: frequent full rebuilds, corpora where CPU builds take hours, or high-QPS batch retrieval. For a static 1M-chunk corpus at tens of QPS, CPU HNSW is simpler.

Reranker sizing

A cross-encoder reads the query and each candidate together, so its cost scales with candidates x tokens per pair on every query.

A standard approximation for a Transformer forward pass is C_forward ≈ 2N + 2 n_layer n_ctx d_attn FLOPs per token, where N is non-embedding parameters ^[15], with N ≈ 12 n_layer d_model². bge-reranker-v2-m3 uses 24 layers with hidden size 1024 ^[16].

Worked estimate (assumptions labelled):

• Non-embedding parameters: 12 x 24 x 1024² = 301,989,888 (about 302M; the rest of the 568M total is the 250,002-token vocabulary embedding, which costs a lookup, not matrix FLOPs).
• FLOPs per token at 512-token pairs: 2 x 301,989,888 + 2 x 24 x 512 x 1024 = 629,145,600 (about 0.63 GFLOP).
• Assumption: 50 candidates per query, each pair padded or truncated to 512 tokens. Tokens per query: 50 x 512 = 25,600.
• Rerank compute per query: 25,600 x 0.629 GFLOP ≈ 16.1 TFLOP.
• For comparison, embedding a 32-token query with bge-m3 (same backbone): 32 x (2 x 301,989,888 + 2 x 24 x 32 x 1024) ≈ 19.4 GFLOP. The rerank step is roughly 830 times more compute.
• At an assumed 20 QPS peak: 20 x 16.1 ≈ 322 TFLOP/s of sustained demand, before any efficiency loss.

Consequences: at TEI's default --max-batch-tokens of 16384, one query's 25,600 rerank tokens span at least two batches, and 50 inputs exceed the default --max-client-batch-size of 32 per request ^[2], so tune both or split requests. The cheapest optimizations are on the workload: fewer candidates, shorter chunks or a smaller reranker. The bge-reranker-v2-m3 card notes that fp16 "speeds up computation with a slight performance degradation" ^[16].

Converting FLOPs to GPUs needs an achieved throughput only measurement gives: send real query-plus-candidate sets at rising concurrency and record p95 latency and tokens per second.

Ingestion vs query capacity planning

Ingestion compute, worked. Using the same bge-m3 backbone:

• Assumption: 10M chunks x 512 tokens = 5.12 billion tokens.
• Compute: 5.12e9 x 0.629 GFLOP ≈ 3.22e18 FLOP.
• If a deployment sustained an assumed 50 TFLOP/s effective: 3.22e18 / 5e13 ≈ 64,400 s ≈ 17.9 hours. At an assumed 200 TFLOP/s effective: about 4.5 hours.

These effective rates are placeholders, not GPU specifications; achieved FLOP/s depends on precision, kernels, padding and length mix. The useful conclusion: a full re-embed scales linearly with corpus tokens and roughly with non-embedding parameters, so an 8B embedder costs over an order of magnitude more.

Plan capacity in three buckets:

1. Steady query load: query embedding, ANN search (RAM), reranking (GPU at p95 target).
2. Incremental ingestion: usually small; can share query GPUs off-peak.
3. Full re-embed and rebuild after a model or chunking change: size for your window; old and new index coexist during cutover.

See CPU vs GPU inference cost for moving small-model work, such as query embedding, to CPU.

Reference configurations (derived examples)

Computed from the formulas above (1024 dimensions, 512-token chunks, bge-m3-class models); starting points for a test, not validated builds.

Replication multiplies the index figures: Qdrant's formulas start from number_of_points * replication_factor ^[6].

Benchmarking protocol

Before buying hardware, measure:

1. Ground truth. Exact top-k for a sample of real queries by brute-force search.
2. Recall@k vs QPS curves. Sweep search parameters (ef for HNSW, itopk_size for CAGRA) and plot recall against throughput, the quality-performance trade-off ANN-Benchmarks was built to evaluate ^[17]. Report QPS at your recall target, not peak QPS.
3. Quantization check. Verify recall against unquantized results; Qdrant notes some embedding models quantize poorly ^[6].
4. Embedding and reranker throughput in tokens per second, with p95/p99 latency at rising concurrency.
5. End-to-end quality after reranking, on a labelled set from your own documents.
6. Peak memory during builds; the CAGRA guide's (observed_peak - formula) / formula headroom method works for any engine.

When to co-locate with the LLM

Sharing GPUs with the generator works when the embedder and reranker need a few GB of weights and their bursts do not collide with prefill peaks, or you isolate them. Options are MIG partitions (hard memory and compute isolation) or MPS and time-slicing (softer); see GPU sharing with MIG and MPS. The cuVS guide warns that running other GPU work beside a persistent CAGRA search kernel "can be fragile" and offers persistent_device_usage to reserve less than the full GPU ^[8]. Move the reranker to its own GPU or slice once its p95 tracks LLM load, and keep full re-embeds off serving GPUs.

GPU Smith helps teams size and benchmark private retrieval stacks against their own corpora; contact us.
