Serving Vision-Language Models: Image Tokens and GPU Memory

Why text-only sizing breaks for VLMs

A vision-language model (VLM) has roughly the weight footprint of its text-only sibling, but each request carries images that become hundreds or thousands of extra tokens before the language model reads the prompt. A text-only calculator sized from prompt length, output length and concurrency therefore undercounts KV cache, prefill compute and time to first token, sometimes by an order of magnitude, and for dynamic-resolution models the error depends on the pixel dimensions users upload.

This guide treats image resolution as a capacity variable: it counts visual tokens for fixed- and dynamic-resolution models, converts them into KV cache bytes, lists the extra memory pools a multimodal engine allocates, and maps the result onto vLLM flags. Flags and defaults were checked against the vLLM v0.32.0 source (released 2026-10-18, the newest release on PyPI) and the "latest" docs on 2026-10-28; they change often and should be rechecked against the deployed version.

Anatomy of a VLM request

Most open VLMs have three stages. A vision encoder, typically a Vision Transformer (ViT), cuts the image into patches and treats each as a token; the ViT paper ("An Image is Worth 16x16 Words") showed that "a pure transformer applied directly to sequences of image patches" performs well on image classification ^[1]. A projector (often a small MLP) maps encoder outputs into the language model's embedding space, where they are processed as ordinary prompt tokens and occupy KV cache slots exactly like text.

LLaVA-1.5, the canonical fixed-resolution example, uses "CLIP-ViT-L-336px with an MLP projection" ^[2]. The 7B checkpoint pairs openai/clip-vit-large-patch14-336 with an mlp2x_gelu projector and a Llama-architecture model of 32 layers, 32 key-value heads and hidden size 4096 ^[3].

Qwen2-VL and Qwen2.5-VL use a ViT with 14x14 patches and then merge each 2x2 group of adjacent patches into one token, so one language-model token represents a 28x28-pixel area ^[4][5]. The Qwen2-VL encoder has "approximately 675 million parameters" ^[4]; the Qwen2.5-VL report gives the ViT's shape (32 layers, hidden size 1280) but no parameter total ^[5]. Summing the visual.* tensors in the 7B checkpoint's safetensors headers gives 676,550,144 parameters, encoder plus merger (our count). The encoder is small next to the language model, but its activations scale with image size.

Counting image tokens

Fixed resolution: LLaVA-1.5

For a fixed-resolution encoder the token count is constant. The LLaVA-1.5 processor config sets patch_size 14 and num_additional_image_tokens 1 ^[6]; the latter accounts for a CLS token added by the backbone ^[7]. The arithmetic is:

• 336 px / 14 px per patch = 24 patches per side
• 24 x 24 = 576 patch tokens (the CLS token is not passed to the language model; the original checkpoint selects patch features, per its config.json)

This derived value matches the image_seq_length default of 576 in Transformers' LlavaConfig ^[7]. Every image costs 576 tokens whatever its original size, because the processor resizes it to 336x336: capacity planning is easy, but detail in large documents is lost.

Dynamic resolution: Qwen2-VL and Qwen2.5-VL

Qwen2-VL's "Naive Dynamic Resolution" maps different resolutions to different token counts. Its worked example: a 224x224 image "encoded with a ViT using patch_size=14, will be compressed to 66 tokens before entering LLM" ^[4]. Arithmetic: 224/14 = 16 patches per side, 16 x 16 = 256 patches, / 4 = 64 merged tokens, plus <|vision_start|> and <|vision_end|> special tokens, for 66.

For Qwen2.5-VL the processor resizes the image to multiples of 28 per side, with total pixels between min_pixels and max_pixels and aspect ratio roughly preserved (the smart_resize function in Transformers' Qwen2-VL image processor). The token count is then (height / 28) x (width / 28). The model card gives "the default range for the number of visual tokens per image" as 4-16384 and an example of min_pixels = 256*28*28 and max_pixels = 1280*28*28 for 256-1280 tokens ^[8]. The shipped preprocessor_config.json sets min_pixels to 3136 (4 x 784) and max_pixels to 12,845,056 (16,384 x 784) ^[9].

One inconsistency matters. The vLLM memory guide comments that the Qwen2.5-VL max_pixels "Default is 1280 * 28 * 28" ^[10]. That is the Transformers class default, but the processor overrides it with any max_pixels in the checkpoint's config ^[11], and the official checkpoint ships 12,845,056. Capacity work should therefore assume up to 16,384 tokens per image unless capped, and confirm by sending a known-size image and reading prompt_tokens in the response usage.

Table 1: Derived Qwen2.5-VL tokens per image

Computed with the smart_resize logic above (excluding the two vision special tokens). Values are derived, not measured.

A 12 MP photo costs about 27 times the tokens of a LLaVA-1.5 image under the shipped defaults, and about twice as many once max_pixels is capped; the cap is the largest single capacity lever.

Memory components

Table 2: Memory pools in a vLLM VLM deployment

Weights

Qwen2.5-VL-7B-Instruct has 8,292,166,656 BF16 parameters ^[12], or 15.4 GiB (x 2 bytes / 2^30); Qwen2.5-VL-72B-Instruct has 73,410,777,344 ^[13], or 136.7 GiB. Both totals include the vision encoder.

KV cache per visual token

KV bytes per token = 2 (K and V) x layers x KV heads x head dimension x bytes per element. With BF16 cache (2 bytes):

• Qwen2.5-VL-7B: 28 layers, 4 KV heads, head dimension 3584 / 28 = 128 (config.json). 2 x 28 x 4 x 128 x 2 = 57,344 bytes = 56 KiB per token.
• Qwen2.5-VL-72B: 80 layers, 8 KV heads, head dimension 8192 / 64 = 128 (config.json). 2 x 80 x 8 x 128 x 2 = 327,680 bytes = 320 KiB per token.
• LLaVA-1.5-7B: 32 layers, 32 KV heads (no grouped-query attention), head dimension 128 (config.json). 2 x 32 x 32 x 128 x 2 = 524,288 bytes = 512 KiB per token.

Per image: LLaVA-1.5-7B, 576 x 512 KiB = 288 MiB; Qwen2.5-VL-7B, 1,369 x 56 KiB ≈ 74.9 MiB at 1024x1024 and 10,549 x 56 KiB ≈ 576.9 MiB for an uncapped 4K frame; Qwen2.5-VL-72B, 10,549 x 320 KiB ≈ 3.2 GiB for the same frame. Attention layout matters as much as token count: LLaVA-1.5's full multi-head attention makes its 576 tokens cost as much KV as a roughly 4-megapixel image on Qwen2.5-VL-7B. Block allocation details are in the KV cache memory calculator and the vLLM KV cache capacity planner.

Encoder activations and profiling

At startup vLLM profiles peak memory with dummy inputs and gives the remainder (within gpu_memory_utilization, default 0.92 in v0.32.0 source ^[14]) to the KV cache, logged as "Available KV cache memory" ^[15]. For a VLM the dummy inputs include maximum-size images, so a model accepting 16,384-token images reserves activations for 65,536 pre-merge patches through a 32-layer ViT. Qwen2.5-VL's window attention means "computational cost scales linearly with the number of patches", but "only four layers employ full self-attention" ^[5]. --skip-mm-profiling skips this step and "shifts the responsibility to users" for estimating encoder peak memory ^[16].

Encoder cache

vLLM holds encoder outputs in an encoder cache, sized in embeddings, so an image's embeddings can be consumed across chunked-prefill steps and shared between requests carrying the same image ^[17]). Its size is the larger of max_num_batched_tokens and the largest per-item token count, and "is not currently configurable" ^[18][17]. Each Qwen2.5-VL-7B embedding has the language model's width (out_hidden_size 3584 in config.json), so a 16,384-embedding cache is 16,384 x 3,584 x 2 bytes = 112 MiB (derived). It is modest, but the docs warn that encoder cache size "is determined by the actual inputs at runtime and is not limited by these hints" (^[10].

Processor cache (host RAM)

mm_processor_cache_gb (default 4 GiB) avoids reprocessing repeated inputs ^[19]. The source notes it "is duplicated for each API process and engine core process", for a total of mm_processor_cache_gb * (api_server_count + data_parallel_size) ^[16]. One API server at DP=1 therefore uses 8 GiB of host RAM by default.

Token budget worksheet

The worksheet multiplies tokens per image (Table 1), images per request and concurrent sequences.

1. Tokens per request = (images x (tokens per image + 2 special tokens)) + text prompt tokens + output tokens.
2. KV tokens in flight = tokens per request x concurrent sequences.
3. KV bytes = KV tokens x KV bytes per token.

Illustrative workload, Qwen2.5-VL-7B: each request carries four 12 MP phone photos, a 300-token text prompt and up to 500 output tokens; 32 requests run concurrently.

• Uncapped (checkpoint max_pixels): 4 x (15,552 + 2) + 300 + 500 = 63,016 tokens per request. x 32 = 2,016,512 tokens. x 56 KiB = ≈107.7 GiB of KV cache.
• Capped at max_pixels = 1280*28*28: 4 x (1,230 + 2) + 800 = 5,728 tokens per request. x 32 = 183,296 tokens. x 56 KiB = ≈9.8 GiB.

The same model, prompt and concurrency differ by about 11x in KV demand purely through the resolution cap. The uncapped request also exceeds the 32,768-token context that the model card says the shipped config targets without YaRN ^[8]. vLLM will not reject it by default, because it derives max_model_len from max_position_embeddings, which is 128,000 in config.json; quality past 32K is simply unvalidated. Set --max-model-len 32768 or enable YaRN deliberately. The operator should run the worksheet on 50th and 99th percentile image sizes from production logs, not one "typical" image.

vLLM knobs that bound memory

Table 3: Multimodal flags

Defaults per the vLLM engine args page and multimodal.py at tag v0.32.0.

The vLLM memory guide notes that fewer "multi-modal items per prompt" reduce "the memory footprint of the model", and that a limit of zero disables a modality ^[10]; the server CLI form is --limit-mm-per-prompt.image 2 ^[20]. The per-modality form also accepts size hints, e.g. {"image": {"count": 5, "width": 512, "height": 512}}. These hints "affect memory profiling only" and "do not change how inputs are actually processed at inference time" ^[10]. A 512x512 hint frees activation reserve at startup, but uncapped 12 MP uploads are still processed at full token count, so the hint and the processor cap should be set together to the same effective size.

Per-request processor overrides are rejected by default on the server; enabling them requires --trust-request-mm-kwargs ^[20]. That flag lets tenants raise their own resolution. Transformers now deprecates call-time min_pixels/max_pixels in favor of a size dictionary ^[11], so the cap's spelling may change.

Prefill pressure and TTFT

Visual tokens are prompt tokens, so they inflate prefill: one uncapped 4K frame on Qwen2.5-VL-7B adds over 10,000 prompt tokens plus the ViT pass. Two latency consequences follow (metrics as defined in TTFT and goodput metrics).

First, chunked prefill spreads a long multimodal prompt over several steps bounded by max_num_batched_tokens, protecting other sequences' inter-token latency but lengthening the image request's TTFT. The scheduler option disable_chunked_mm_input avoids splitting a multimodal item, and errors if the largest item exceeds max_num_batched_tokens ^[18][17]. Second, the per-step encoder compute budget is also the larger of max_num_batched_tokens and the largest item, so one very large image can monopolize a step. Capping resolution reduces tail TTFT as well as memory.

GPU fit scenarios

Table 4 applies the worksheet to single-image chat: one image, 300 text tokens, 500 output tokens. "Capped" uses max_pixels = 1280*28*28 (1,222 tokens for a 1920x1080 input, Table 1); "4K uncapped" uses 10,549 tokens. Assumptions, all illustrative: card capacity taken as nominal GiB, gpu_memory_utilization 0.92, BF16 weights and KV cache, and a flat 1.5 GiB per GPU for activations, encoder profiling reserve and CUDA graphs. The real reserve should be read from the "Available KV cache memory" log line.

Table 4: Illustrative fit, Qwen2.5-VL in BF16

KV pool = budget - weights - overhead (e.g. 22.1 - 15.4 - 1.5 = 5.1 GiB); KV tokens = pool x 2^20 / KiB per token (56 or 320). Concurrency figures are KV-bound ceilings; max_num_seqs, compute and latency targets usually bind first. The 72B on two 80 GiB cards fits but, at about two concurrent 4K-image requests, is a test rig rather than a serving configuration. Weight quantization moves these numbers considerably; the inference hardware sizing guide covers that trade-off.

Video and multi-image caveats

Qwen2-VL samples video at two frames per second and caps "the total number of tokens per video to 16384" ^[4]. Qwen2.5-VL groups "two consecutive frames" together and samples at dynamic FPS ^[5], matching temporal_patch_size 2 in the processor config ^[9]. Illustratively, vLLM's profiling example of 32 frames at 640x640 ^[10] resizes to 644x644, or 23 x 23 = 529 tokens per two-frame group; 16 groups give 8,464 tokens, or ≈463 MiB of KV on Qwen2.5-VL-7B. Real counts also depend on video pixel settings such as total_pixels ^[20].

GPU-side video decoding requires a positive --mm-ipc-gpu-memory-gb "to reserve VRAM for video decoding" ^[20], and that reserve "is carved out of the engine's KV-cache memory" ^[16]. Video token pruning (--video-pruning-rate, method evs by default in source) reduces tokens, but "enabling video pruning also disables encoder CUDA graphs, since the retained token count becomes data-dependent" ^[20]. The KV saving may be partly paid back in encoder latency.

For multi-image prompts the default limit is 999 items per modality ^[19], so without an explicit limit_mm_per_prompt a single client can submit a document's worth of page images in one request.

Operational checklist

Table 5: Pre-production checklist for VLM serving

GPU Smith can review a VLM serving configuration against representative traffic.
