Kueue Quotas, Cohorts and Fair Share for GPU Clusters

The short answer

To share a GPU cluster between teams with Kueue, create one ResourceFlavor per GPU model and give each team a ClusterQueue with a nominalQuota of GPUs. Put the ClusterQueues in one cohort so idle GPUs can be borrowed. Cap bursts with borrowingLimit, protect a floor with lendingLimit, and set reclaimWithinCohort so teams can take their quota back. Add fair sharing when first-come, first-served borrowing stops being acceptable. As of 2026-10-28 the latest release is Kueue v0.20.3, published 2026-10-22, alongside v0.19.10 on the previous minor line ^[1]. Since v0.20.0 Kueue no longer serves kueue.x-k8s.io/v1beta1 ^[2], so every manifest below is v1beta2.

This article covers quota policy. Gang placement is covered in gang scheduling on Kubernetes, and splitting one device between workloads in MIG, MPS and time-slicing.

The multi-tenant GPU quota problem

Hard per-team GPU slices leave GPUs idle while other queues grow. No slices at all lets the first submitter take the cluster. Kueue "manages quotas and how jobs consume them": it decides when a job waits, is admitted or is preempted. Pod-to-node placement stays with kube-scheduler ^[3]. For each team and GPU model you are really choosing three things:

• a guaranteed floor, the GPUs the team gets back quickly;
• a burst cap, how far above the floor it may go when others are idle;
• a reclaim cost, the running work you are willing to destroy to hand quota back.

The Kueue object model

Jobs opt in through the labels kueue.x-k8s.io/queue-name and, optionally, kueue.x-k8s.io/priority-class ^[10][9].

ResourceFlavors for GPU models

Every NVIDIA GPU is requested as nvidia.com/gpu. The Kueue docs call this out: with T4 and A100 GPUs in one cluster, the system "may not differentiate between them" ^[4]. The fix is one flavor per hardware type:

• spec.nodeLabels ties a flavor to nodes. When a Workload is admitted, Kueue adds these labels to its pod template's nodeSelector, so the pods run where the quota was charged.
• spec.tolerations is injected into admitted pods, which lets them land on tainted GPU nodes automatically.
• spec.nodeTaints works the other way round. Only Workloads that already tolerate the taint can use the flavor, and Kueue does not inject that toleration. This suits pools that users must opt into (same source).

NVIDIA GPU Feature Discovery labels each node with nvidia.com/gpu.product, with example values such as A100-SXM4-40GB and Tesla-T4. The value "may be modified by the device plugin if a sharing strategy is employed", and it carries MIG information when MIG is enabled ^[11]. GFD builds it from the NVML device name with spaces turned into hyphens (resource.go), so an H100 SXM 80 GB node reports NVIDIA-H100-80GB-HBM3 and an A100 SXM4 80 GB node NVIDIA-A100-SXM4-80GB. Copy the exact string from kubectl get nodes -L nvidia.com/gpu.product. Check it again after sharing or driver changes; see GPU Operator and DRA upgrade gate.

# Assumption: GPU nodes are tainted nvidia.com/gpu:NoSchedule.
# NVIDIA-H100-80GB-HBM3 is the H100 SXM 80 GB value; copy yours from the node labels.
apiVersion: kueue.x-k8s.io/v1beta2
kind: ResourceFlavor
metadata:
  name: h100
spec:
  nodeLabels:
    nvidia.com/gpu.product: NVIDIA-H100-80GB-HBM3
  tolerations:
  - key: nvidia.com/gpu
    operator: Exists
    effect: NoSchedule

Create an a100 flavor the same way.

ClusterQueue quotas

A ClusterQueue lists resourceGroups. Each group has coveredResources and an ordered list of flavors with a quota per resource. When a flavor maps to a node pool, put cpu, memory and nvidia.com/gpu in the same group so all three are charged to the same flavor ^[5]. The CRD also requires every flavor to list every covered resource ^[12]. The three per-resource fields are ^[13]:

• nominalQuota: what the queue can use at any time. It should reflect capacity "after discounting resources consumed by system components and pods not managed by kueue".
• borrowingLimit: the most the queue may borrow from unused quota in its cohort, which caps it at nominalQuota + borrowingLimit. If unset, borrowing is unlimited. It must be null when the queue has no cohort.
• lendingLimit: the most unused quota the queue lends out. The queue keeps nominalQuota - lendingLimit for exclusive use. The webhook rejects a lendingLimit larger than nominalQuota ^[14]. The docs list lending limits as stable since v0.17 ^[5].

Kueue tries flavors in list order and takes the first one with enough unused quota in the queue or its cohort. Listing h100 before a100 therefore makes A100 the fallback. By default (whenCanBorrow: MayStopSearch), Kueue stops at the first flavor that fits by borrowing. Set flavorFungibility.whenCanBorrow: TryNextFlavor if teams should prefer in-quota A100s over borrowed H100s (same source). queueingStrategy orders Workloads by priority, then creation time. Under StrictFIFO, an older Workload that does not fit blocks newer ones. Under BestEffortFIFO, the default, newer Workloads that fit can go ahead.

Cohorts and hierarchy

ClusterQueues join a cohort through spec.cohortName. Some prose on the ClusterQueue page still says .spec.cohort, but the v1beta2 examples and the API reference use cohortName. A request fits by borrowing when it exceeds the queue's unused nominalQuota but stays within both (1) the cohort's total unused nominalQuota and (2) the queue's unused nominalQuota + borrowingLimit. A queue can borrow only for flavors it defines, even when it defines them at nominalQuota: 0 ^[5]. The "dedicated and fallback flavors" layout in Administer Cluster Quotas uses this rule. Each team gets dedicated quota on one flavor and zero on another, and a separate shared ClusterQueue owns that second flavor. It is a clean way to run a shared A100 pool next to dedicated H100 slices.

A Cohort can also be an object in its own right. Its nominalQuota is "additional resources on top of those defined by ClusterQueues within the Cohort", which works as a shared pool ^[8]. Cohorts form trees through spec.parentName. On a child Cohort, borrowingLimit and lendingLimit limit what the whole subtree borrows from or lends to its parent. These limits are rejected on a root Cohort ^[13]. A typical tree has one root per cluster, a child Cohort per business unit, and team ClusterQueues underneath.

Preemption policies

Borrowing does not return quota on its own. reclaimWithinCohort defaults to Never, so a lender waits until the borrower's jobs finish ^[5].

Source: ClusterQueue. Under classic preemption, "ClusterQueues in a cohort borrow resources in a first-come first-served fashion". Victims come first from borrowing queues, then by lowest priority, then by most recent admission, and Kueue trims the set to the minimum that still fits. Preempted Workloads receive Evicted and Preempted conditions that identify the preemptor ^[15]. For GPU training, preemption costs whatever ran since the last checkpoint. Make checkpoint frequency part of each tenant's quota contract.

Worked example: three teams, 64 H100s

All numbers are assumptions. The cluster has 64 H100 GPUs (8 nodes × 8) in flavor h100, and the A100 pool is full, so nothing falls back to it. Three ClusterQueues share cohort ml-platform, all with reclaimWithinCohort: Any. Research runs 8-GPU jobs.

The nominal quotas add up to the physical 64 GPUs. Kueue does not enforce that, but if the sum is too high, admitted pods sit unschedulable.

Step 0: research bursts. Product-training is using 6 GPUs and eval 0.

• Product-training can lend 12, because its 6 GPUs fit inside its 12-GPU exclusive floor. Eval can lend 8. Available to borrow: 12 + 8 = 20.
• Research ceiling: 32 + min(16, 20) = 48 GPUs, which is six 8-GPU jobs.
• Allocated: 48 + 6 + 0 = 54. Idle: 10. Six are product-training's unused floor (12 − 6) and four are cut off by research's borrowingLimit (20 − 16).

Step 1: product-training submits a 16-GPU job. 6 + 16 = 22 ≤ 24, so the job is within nominal and may reclaim. Ten GPUs are free, so 6 more are needed. Research is the only queue above nominal (48 > 32), and preempting one 8-GPU research job is enough. Result: research 40, product-training 22, eval 0. Total 62, free 2.

Step 2: eval submits an 8-GPU job. That is within its nominal of 8. Six more GPUs are needed, so one more research job is preempted. Result: research 32 (borrowing 0), product-training 22, eval 8. The 2 free GPUs are product-training's, and research may borrow them because 12 − (22 − 12) = 2 are still lendable.

With the defaults (reclaimWithinCohort: Never), the 16-GPU job in step 1 waits until two research jobs finish. On multi-day runs, that wait is where most "Kueue took our GPUs" complaints come from.

lendingLimit buys latency, not throughput. Product-training can always start 6 more GPUs instantly, with no preemption and no lost checkpoints, and pays for it with 6 idle GPUs in step 0. This walk-through applies the documented rules by hand. It is not a measurement, so replay it on a staging cluster.

The research queue, with CPU and memory at an assumed 12 CPU and 120Gi per GPU:

apiVersion: kueue.x-k8s.io/v1beta2
kind: ClusterQueue
metadata:
  name: research
spec:
  cohortName: ml-platform
  namespaceSelector:
    matchLabels:
      tenant: research
  queueingStrategy: BestEffortFIFO
  preemption:
    reclaimWithinCohort: Any
    withinClusterQueue: LowerPriority
  resourceGroups:
  - coveredResources: ["cpu", "memory", "nvidia.com/gpu"]
    flavors:
    - name: h100
      resources:
      - name: cpu
        nominalQuota: 384
      - name: memory
        nominalQuota: 3840Gi
      - name: nvidia.com/gpu
        nominalQuota: 32
        borrowingLimit: 16
    - name: a100            # fallback: borrowed from a shared A100 ClusterQueue
      resources:
      - name: cpu
        nominalQuota: 0
      - name: memory
        nominalQuota: 0
      - name: nvidia.com/gpu
        nominalQuota: 0
---
apiVersion: kueue.x-k8s.io/v1beta2
kind: LocalQueue
metadata:
  namespace: research
  name: research-gpu
spec:
  clusterQueue: research

Product-training uses nominalQuota: 24 and lendingLimit: 12 on nvidia.com/gpu. Give cpu and memory proportional lending limits (144 and 1440Gi) so the floor reserves whole nodes' worth of resources, not just GPUs.

Fair sharing

Classic preemption guarantees nominal quota but leaves idle quota with whoever borrowed it first. Fair sharing preempts "until the preempting ClusterQueue obtains an equal or weighted share of the borrowable resources". It has been stable since v0.7 ^[15]. In the v1beta2 Configuration, the fairSharing block holds only preemptionStrategies ^[16]. v0.15 removed the old enable field and made preemptionStrategies required ^[17]. The manager turns fair sharing on when the block is present ^[18].

apiVersion: config.kueue.x-k8s.io/v1beta2
kind: Configuration
metrics:
  enableClusterQueueResources: true
fairSharing:
  preemptionStrategies: [LessThanOrEqualToFinalShare, LessThanInitialShare]

Only three lists are accepted: [LessThanOrEqualToFinalShare], [LessThanInitialShare], or both in that order. Any other list "fails configuration validation and Kueue does not start". Fair sharing works with reclaimWithinCohort and withinClusterQueue, but borrowWithinCohort is classic-only ^[15].

A queue's share is "the maximum of the ratios of usage above nominal quota to the lendable resources in the Cohort, among all the resources", divided by spec.fairSharing.weight ^[13]. This is a Dominant Resource Share, or DRS ^[19]. Kueue admits from the lowest share first and preempts from the highest. In v0.20.3 the ratio is computed per thousand, and .status.fairSharing.weightedShare reports it rounded up to an integer ^[20]. A weight of zero makes any borrowing an infinite share.

Worked example (assumptions). One flavor, 64 GPUs and no lending limits, so lendable = 64. Queues A and B have nominal 24 each, and C has nominal 16 and is idle. A runs 36 GPUs (borrowing 12) and B runs 28 (borrowing 4), so the cluster is full. Weights are 1.

• Share A = 12/64 = 187.5 per thousand. Share B = 4/64 = 62.5.
• B submits a 4-GPU job. B's share with the job admitted is 8/64 = 125. A's share without one of its 4-GPU jobs is also 8/64 = 125. Since 125 ≤ 125, LessThanOrEqualToFinalShare holds and the A job is preempted. Both queues end at 32 GPUs.
• B submits an 8-GPU job instead. B with the job: 12/64 = 187.5. A after losing 8 GPUs: 62.5. 187.5 ≤ 62.5 fails, and LessThanInitialShare (187.5 < 187.5) also fails, so B waits. Flipping the imbalance gains nothing. The Fair Sharing page proves that two workloads in different ClusterQueues cannot keep preempting each other.
• With A at weight 2, B's 4-GPU job would need 125 ≤ 125/2 = 62.5, which fails. A keeps its borrowed GPUs.

In a Cohort tree, the strategies compare the queues' "AlmostLCA" ancestors rather than the queues themselves ^[15]. Cohort weights of 0.75 and 0.25 make two orgs "trend towards using 75%" and 25% of common resources ^[8].

Admission Fair Sharing (AFS) is for many LocalQueues feeding one ClusterQueue. It orders Workloads by the decayed historical usage of their LocalQueue, and an entry penalty stops a tenant from flooding the queue before its usage catches up. It is beta and on by default since v0.15. A ClusterQueue opts in with spec.admissionScope.admissionMode: UsageBasedAdmissionFairSharing, and usageHalfLifeTime, usageSamplingInterval, resourceWeights and a per-LocalQueue fairSharing.weight tune it ^[21]. In v0.20, usage counts from quota reservation, and disabling AdmissionFairSharing without also disabling AdmissionFairSharingAnchorAtQuotaReservation is rejected at startup ^[2].

Reference designs

These patterns combine. A common shape is a weighted Cohort tree at the top, floors on production queues, and AFS inside a shared research queue.

Accounting and chargeback

Kueue measures quota held, not GPU work done. A job holding 8 GPUs at low SM activity is still charged 8, so pair Kueue's numbers with device telemetry; see GPU utilization targets. Four per-flavor gauges are exported only when metrics.enableClusterQueueResources is set: kueue_cluster_queue_resource_usage, kueue_cluster_queue_nominal_quota, kueue_cluster_queue_borrowing_limit and kueue_cluster_queue_lending_limit. They are labelled cohort, cluster_queue, flavor, resource and replica_role ^[22]. The docs still mark LocalQueue metrics such as kueue_local_queue_resource_usage as alpha behind LocalQueueMetrics, but in the v0.20.3 source that gate has been Beta and on by default since v0.17 ^[23].

Reserved GPU-hours per queue and flavor over 30 days:

sum by (cluster_queue, flavor) (
  sum_over_time(kueue_cluster_queue_resource_usage{resource="nvidia.com/gpu", replica_role!="follower"}[30d:5m])
) * 5 / 60

Each 5-minute sample is a GPU count. Multiplying the sum of samples by 5 gives GPU-minutes, and dividing by 60 gives GPU-hours. For borrowed GPU-hours, subtract kueue_cluster_queue_nominal_quota and clamp at zero. replica_role is leader, follower or standalone ^[24]; the filter drops followers so an HA install is not double counted. For tenant SLOs, track kueue_admission_wait_time_seconds and kueue_preempted_workloads_total (same source).

Failure modes

• Lent quota never returns. reclaimWithinCohort was left at Never.
• Head-of-line blocking. Under StrictFIFO, one 64-GPU job that does not fit blocks everything behind it. The reverse risk under BestEffortFIFO is our inference: small jobs keep fitting and large ones wait. Use priorities or a separate queue for large jobs.
• Borrowing storms. Without borrowingLimit, one team can absorb the whole idle pool, and the owners' return then preempts many large jobs at once. Cap borrowing at what you can afford to lose.
• Quota that does not match the hardware. Nominal sums above allocatable GPUs, or nodeLabels that no longer match nodes, produce admitted pods that stay Pending. The gang scheduling article covers waitForPodsReady and topology.
• Configuration that will not start. An unsupported strategy list, borrowWithinCohort combined with fair sharing, or disabling AFS alone in v0.20 is rejected ^[15][2].
• Zero weights. A queue with weight 0 always loses as soon as it borrows.

Rollout checklist

1. Pin a version: v0.20.3, or v0.19.10 on the previous minor, as of October 2026. Read every .0 release note you cross, and run the v1beta2 migration script if you are coming from v1beta1 ^[2].
2. Take an inventory of GPU node labels and taints, then create one ResourceFlavor per model and confirm that it matches real nodes.
3. Set nominal quotas from allocatable GPUs minus system usage, and check the sum for each flavor.
4. Write each tenant's contract down: nominal quota, burst cap, floor, preemption exposure and checkpoint interval.
5. Enable enableClusterQueueResources and build the GPU-hour and admission-wait dashboards before go-live.
6. Replay a representative week of jobs in staging, including a reclaim drill like steps 1 and 2 above. Kueue has no built-in dry-run admission mode that we could verify.
7. Onboard tenants one namespace at a time with namespaceSelector, and keep stopPolicy: Hold ready for any queue that misbehaves ^[5].
8. Add fair sharing only after classic reclaim works and tenants have agreed on weights.
