TensorRT-LLM for Private Deployments: trtllm-serve Guide

What TensorRT-LLM is in October 2026

TensorRT-LLM (now styled "TensorRT LLM") is NVIDIA's Apache 2.0 open-source library for LLM inference on NVIDIA GPUs ^[1][2]. Current TensorRT-LLM is a PyTorch-native runtime. It loads Hugging Face checkpoints directly and serves them through trtllm-serve, an OpenAI-compatible HTTP server. The old "convert checkpoint, then trtllm-build an engine" workflow is gone from the development line but still present in the last stable release. Choosing between them is your first decision.

As of 2026-10-28 the release picture is:

The public docs track the development tree; on 2026-10-28 they were generated from the 1.4.0rc2 source ^[6]. Flags and defaults below come from those docs, with v1.2.1 differences checked against the tagged source.

Where it fits in a private stack

TensorRT-LLM is the runtime: execution, batching, KV cache, parallelism and quantized kernels. NVIDIA positions its LLM API as integrating with Dynamo and Triton Inference Server ^[1], which gives three ways to run it:

1. trtllm-serve directly, one server process (or one Slurm/MPI job) per model replica, behind your own gateway. This is the focus here.
2. Inside Dynamo, for disaggregated prefill/decode and KV-aware routing; the docs include a Dynamo Kubernetes example.
3. Behind Triton. Check packaging first: the 26.08 release notes say the TensorRT-LLM backend container "is not included in this release", and NGC lists no -trtllm- Triton tag after 26.07 (^[7]; runbook).

Lock-in is mostly hardware. The supported-hardware list contains only NVIDIA parts: Blackwell (B200, GB200, B300, GB300, DGX Spark), Hopper (H100, H200, GH200), Ada Lovelace (L20, L40/L40S) and Ampere (A100) ^[8]. Clients see an OpenAI-compatible API, so switching costs sit in runtime configuration and quantized checkpoints.

The PyTorch-native architecture and what was removed

TensorRT-LLM 1.0 made "the PyTorch-based architecture ... stable and the default experience" ^[9]. The development line has since removed the engine path: "PyTorch is now the sole execution backend" ^[10]. trtllm-build, trtllm-refit, trtllm-prune and per-model convert_checkpoint.py scripts are gone. LLM(backend="tensorrt") raises ValueError, and the tensorrt pip dependency is no longer installed (same source). Two-model speculative decoding was removed too; only one-model Eagle3/MTP paths remain ^[9].

When the removal happened matters for version pinning. The release-notes page lists the removal under its "Release 1.2" heading, but the tagged source disagrees. v1.2.1's setup.py still registers trtllm-build, trtllm-prune and trtllm-refit as console scripts ^[11]. Its serve command still accepts --backend tensorrt ^[12]. We checked setup.py at each tag: trtllm-build is still present at v1.3.0rc20 and absent from v1.3.0rc21 (published 2026-07-15) onward ^[13]. Prebuilt engines and CI jobs calling trtllm-build are pinned to v1.2.x; moving to 1.3/1.4 means re-validating from Hugging Face or ModelOpt checkpoints.

Since 1.0, deprecated APIs get a 3-month migration period with runtime warnings before removal ^[14], so read the release notes on every bump.

Serving with trtllm-serve

Endpoints

trtllm-serve "starts an OpenAI compatible server" exposing /v1/models, /v1/completions and /v1/chat/completions, plus a Responses API at /v1/responses. It also serves /health, /metrics and /version, prototype /start_profile and /stop_profile endpoints, and render endpoints that are off unless TRTLLM_ENABLE_RENDER_ENDPOINTS=1 ^[15].

A minimal pinned launch (image tag and run flags from NVIDIA's installation guide; the model is a local directory, as an air-gapped site needs):

docker run --rm --ipc host --gpus all \
  --ulimit memlock=-1 --ulimit stack=67108864 \
  -e TRTLLM_NO_USAGE_STATS=1 \
  -v /models:/models -p 8000:8000 \
  nvcr.io/nvidia/tensorrt-llm/release:1.4.0rc2 \
  trtllm-serve /models/Llama-3.1-8B-Instruct-FP8 \
    --host 0.0.0.0 --port 8000 \
    --served_model_name llama-3.1-8b-fp8 \
    --config /models/serve.yaml --no-telemetry

--host defaults to localhost and --port to 8000 in both v1.2.1 and v1.4.0rc2 (serve.py at v1.2.1, serve.py at v1.4.0rc2). In a container, bind 0.0.0.0 deliberately; NVIDIA notes --ipc=host avoids "Bus error (core dumped)" ^[16].

Flags that matter in production (1.4.0rc2 docs)

Sources: trtllm-serve CLI reference; v1.2.1 comparison from serve.py at v1.2.1; defaults from llm_args.py at v1.4.0rc2. Prototype-tagged flags can change between release candidates.

Configuration precedence changed

This is the most common migration trap. Current docs: "Precedence is fixed, regardless of command-line order: LlmArgs defaults < --config < dedicated CLI flags < --set" ^[15]. Previously "YAML overrode CLI" ^[9]; v1.2.1's --config help still reads "Path to a YAML file that overwrites the parameters specified by trtllm-serve" ^[12]. A script with --max_batch_size 64 and max_batch_size: 256 in YAML runs at 256 on 1.2.1 and 64 on 1.4. Keep each setting in one place and diff the effective config after every upgrade.

Do not pass secrets through --set (they can appear in process listings and logs). JSON schemas for validating YAML ship in release containers at /app/tensorrt_llm/schemas/ (same source).

No built-in authentication on the API

The CLI reference lists no API-key or TLS option for the OpenAI endpoints; examples pass a placeholder key ^[15]. In the 1.4.0rc2 source, API keys exist only for optional control endpoints: --enable_sleep_mode requires TRTLLM_RUNTIME_CONTROL_API_KEY (serve.py at v1.4.0rc2, openai_server.py at v1.4.0rc2). Put an authenticating, TLS-terminating gateway in front of every replica and keep /metrics, profiling and kv_cache_events on the cluster network. vLLM has --api-key, but its docs warn it covers only some path prefixes and should not be relied on alone ^[18].

Telemetry: the first thing to switch off on a private cluster

From the 1.3 release-candidate line onward, the README states that "TensorRT-LLM collects anonymous telemetry data by default" ^[14]. The v1.2.1 README has no such section. NVIDIA says the payload excludes prompts, outputs, weights and model paths but includes GPU SKU and count, CUDA version, parallelism, quantization, KV dtype and selected configuration values; the telemetry page lists 334 captured TorchLlmArgs fields ^[19]. It is auto-disabled only in CI and test environments.

The documented opt-outs are: TRTLLM_NO_USAGE_STATS=1, DO_NOT_TRACK=1 or TELEMETRY_DISABLED=true; the file ~/.config/trtllm/do_not_track; TelemetryConfig(disabled=True) in Python; or --no-telemetry on trtllm-serve, trtllm-bench and trtllm-eval (README). On a regulated or air-gapped cluster, set the variable in the image, pass the flag too, and confirm with egress logs. Security review should record the on-by-default behavior.

Hardware and precision support matrix

The quantization page lists ten recipes: FP4, FP8 per-tensor, FP8 block scaling, FP8 rowwise, FP8 KV cache, NVFP4 KV cache, and W4A16/W4A8 in both GPTQ and AWQ form. It states that "the default PyTorch backend supports FP4 and FP8 quantization on the latest Blackwell and Hopper GPUs" ^[20]. Its hardware matrix, transcribed exactly ("Y" = supported, "." = not listed):

Source: Quantization, Hardware Support Matrix, as of 2026-10-28.

• NVFP4 and MXFP4 weights need Blackwell (or Rubin) in this matrix. Hopper is "." for both. Model guides document narrower fallbacks (for example MXFP4 GPT-OSS on Hopper), tracked in our NVFP4 vs MXFP4 vs FP8 runtime compatibility article.
• FP8 block scaling is not the same recipe across generations. NVIDIA notes that on sm100/103/107 the FP8 block-wise GEMMs use the MXFP8 recipe (E4M3 values with UE8M0 scales). SM90 uses E4M3 with FP32 scales ^[20]. Re-run accuracy gates when moving a block-scaled FP8 model from Hopper to Blackwell.
• Blackwell sm120 parts get a much smaller menu than data-center sm100/103 parts: no block or rowwise FP8 and no AWQ/GPTQ. Check your GPU's compute capability (nvidia-smi --query-gpu=compute_cap --format=csv) before choosing a checkpoint.
• Ampere (A100) is limited to W4A16 AWQ/GPTQ and FP8 KV cache in the matrix. On A100s the precision argument for TensorRT-LLM is weak.
• The model matrix also gates you. NVFP4 KV cache, for example, is marked only for LLaMA-v2, LLaMA 3 and Qwen-3 among the listed families (same page).

Quantization recipes and when to pick each

TensorRT-LLM runs pre-quantized checkpoints produced by NVIDIA Model Optimizer (ModelOpt). Where none exists, you quantize offline with ModelOpt's huggingface_example.sh --quant fp8 (or other --quant values) ^[20]. The checkpoint metadata now carries the deployment decision. NVIDIA's Llama-3.1-8B-Instruct-FP8 checkpoint, for example, declares "quant_algo": "FP8" and "kv_cache_quant_algo": "FP8", with lm_head excluded ^[21]. With the default auto KV dtype, it gets an FP8 KV cache without anyone asking.

A pragmatic selection order for private fleets:

NVIDIA's overview claims FP8 "can double performance and halve memory consumption compared to 16-bit floating point, with minimal impact on model accuracy" ^[1]. Treat that as a vendor claim to test on your own models, not a planning number. For the cost side of precision choices, see FP8 and INT4 inference costs.

NVFP4 KV cache has extra constraints. It requires ModelOpt offline quantization, and currently TensorRT-LLM "only supports FP8 weight/activation quantization when NVFP4 KV cache is enabled" ^[20].

KV cache configuration

Defaults

The fraction applies to memory that is free after weights and buffers are allocated, not to total HBM ^[15]. Eviction is prioritized LRU with priorities 0 to 100 (default 35). With host offload enabled, evicted blocks move to host memory and remain reusable until evicted from there ^[22]. Two KV cache managers exist; use_kv_cache_manager_v2: auto lets the model choose (same source).

Worked example: KV capacity for an 8B FP8 model on one 80 GB GPU

Model facts, from the checkpoint config: 32 layers, 8 KV heads, head dimension 128 ^[21]. Its quant config selects FP8 KV (1 byte per element).

1. KV bytes per token = 2 (K and V) x 32 layers x 8 heads x 128 dims x 1 byte = 65,536 bytes = 64 KiB. With a BF16 KV cache it would be 128 KiB.
2. Assumption: after weights, activations and runtime buffers, the startup profiler finds 60 GiB free. This is illustrative; read the real figure from your startup log.
3. KV pool = 0.9 x 60 GiB = 54 GiB = 56,623,104 KiB.
4. Token capacity = 56,623,104 / 64 = 884,736 tokens, which is 27,648 blocks of 32 tokens.
5. At 8,192 tokens of context per request, that is 884,736 / 8,192 = 108 fully grown sequences resident at once. With BF16 KV it would be 54.

The 6 GiB the 0.9 default leaves is headroom; raise the fraction only after a peak-concurrency soak test. NVIDIA's own multi-node DeepSeek example uses 0.95 ^[15]. The same arithmetic, applied to vLLM's allocator, is in our vLLM KV cache capacity planner.

Multi-tenant caution

Block reuse is on by default and matches prefixes across requests ^[22]. Shared system prompts therefore reuse blocks across tenants. If tenants on one replica must not share cache state, separate them by replica or disable reuse (kv_cache_config.enable_block_reuse: false), and measure the throughput cost. Multimodal models currently require block reuse to be disabled anyway ^[15].

In-flight batching, overlap scheduler and feature combinations

In-flight (continuous) batching processes context-phase and generation-phase sequences together in one packed batch. max_num_tokens caps the batched tokens per iteration and defaults to 8192. NVIDIA recommends tuning it: high enough to saturate GPU math, low enough to hold TTFT and TPOT targets ^[23]. Chunked prefill splits long contexts so they can batch with decode work. Each chunk except the last must be a multiple of the KV block size (same source).

The overlap scheduler is enabled by default. It launches GPU work for step n+1 while the CPU finishes step n. NVIDIA states the tradeoff: it "introduces one extra decoding step but significantly improves throughput". Disable it with disable_overlap_scheduler: true ^[24].

Not every feature combines. Pairs from the Feature Combination Matrix worth knowing before you design a config (as of 2026-10-28):

Treat "Untested" as a pilot item. Model-specific limits sit on top; DeepSeek-V4.1's CSA2 attention, for example, does not support PP or CP (same source).

Observability and operations

There are two metrics surfaces, and they behave differently:

• /metrics returns JSON iteration statistics: GPU memory, KV block counts, cache hit rate and active requests. It is populated only when enable_iter_perf_stats: true, which "can slightly impact performance". Statistics are removed from an internal queue once read and are returned to only one caller. NVIDIA advises polling "from a single client" ^[15].
• /prometheus/metrics serves Prometheus exposition with the trtllm_ prefix: request success counts, end-to-end latency, TTFT, queue time and KV cache hit rate, reuse and utilization ^[25]. In the 1.4.0rc2 server, this route is mounted only when return_perf_metrics is true ^[26], and that field defaults to false ^[17]. Histogram buckets are configurable through PrometheusMetricsConfig ^[27].

A baseline YAML for a private replica, using only fields documented on the pages cited above:

# serve.yaml (validate against /app/tensorrt_llm/schemas/ for your version)
max_batch_size: 256
max_num_tokens: 8192
enable_chunked_prefill: true
return_perf_metrics: true        # mounts /prometheus/metrics
enable_iter_perf_stats: false    # turn on only for profiling windows
kv_cache_config:
  free_gpu_memory_fraction: 0.9
  enable_block_reuse: true
  dtype: auto                    # follows the checkpoint's KV quant config

max_batch_size: 256 is an example value, not a recommendation; tune it under load. For version control, record the container tag and TRT_LLM_GIT_COMMIT, which the installation guide says is recorded in the image ^[6]. /version gives the runtime view. NGC tags include both regular and .dev nightly builds, and NVIDIA says nightly quality "is not guaranteed" (same source). Never let a floating tag reach production.

Upgrade gates: read [BREAKING CHANGE] and [DEPRECATION] notes, diff the effective config, validate YAML against the new schema, re-run accuracy and latency gates, re-check the telemetry opt-out.

TensorRT-LLM vs vLLM vs SGLang

No speedup figures here; published benchmarks rarely match a private workload. The comparison is structural:

Choose TensorRT-LLM when the fleet is NVIDIA-only for good, target models have NVIDIA deployment guides and ModelOpt checkpoints, and the team can absorb a fast release cadence. Choose vLLM or SGLang when hardware diversity or recent features in a non-pre-release build matter more.

A fair benchmark protocol:

1. Same checkpoint precision, GPU and TP size on both engines.
2. Replay recorded production prompts, including prefix sharing.
3. Sweep concurrency; report throughput at fixed p95 TTFT and TPOT targets.
4. Golden-prompt accuracy diff against a BF16 reference on both.
5. Measure after warmup.

Adoption checklist and rollback

Before the pilot

• Choose the line: v1.2.1 (stable, still has trtllm-build, older precedence rules) or a pinned 1.4 release candidate (current features, no engine path). Write the reason down.
• Confirm every target model and precision is "Y" in both the model and hardware matrices for your exact GPU architecture.
• Mirror the container image and checkpoints internally; point MODEL at local paths.
• Disable telemetry (environment variable plus --no-telemetry) and verify with egress logs.
• Put an authenticating gateway in front; restrict /metrics, profiling and control endpoints to the cluster network.

During the pilot

• Record startup KV pool size and token capacity; compare with your own arithmetic.
• Golden-prompt accuracy gate vs BF16 for each quantized checkpoint.
• Load test at target concurrency with the overlap scheduler, chunked prefill and block reuse in their intended states.
• Check every feature pair you enable against the combination matrix.

Rollback

• Keep the previous engine (vLLM or the prior TensorRT-LLM tag) deployed on standby with the same served model name, so the gateway can switch upstreams without client changes.
• Keep BF16 or the previous quantized checkpoint available; a precision change and an engine change should never ship in the same release.
• Define the rollback trigger in advance: accuracy-gate failure, p95 TTFT regression beyond your SLO, or KV-capacity shortfall at peak.

GPU Smith helps teams plan and validate private inference stacks on NVIDIA hardware; contact us if you are running this evaluation.

Sources

1. Overview, TensorRT LLM documentation, NVIDIA, page updated 2026-10-26. https://nvidia.github.io/TensorRT-LLM/overview.html
2. trtllm-serve CLI reference, NVIDIA, page updated 2026-10-26. https://nvidia.github.io/TensorRT-LLM/commands/trtllm-serve/trtllm-serve.html
3. Migration Guide: TensorRT Backend Removed, NVIDIA. https://nvidia.github.io/TensorRT-LLM/legacy/tensorrt-backend-removal.html
4. Release Notes, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/release-notes.html
5. NVIDIA/TensorRT-LLM releases, GitHub (v1.2.1 2026-04-20; v1.4.0rc2 2026-10-28). https://github.com/NVIDIA/TensorRT-LLM/releases
6. Release v1.2.1, NVIDIA/TensorRT-LLM, GitHub, 2026-04-20. https://github.com/NVIDIA/TensorRT-LLM/releases/tag/v1.2.1
7. Release v1.4.0rc2, NVIDIA/TensorRT-LLM, GitHub, 2026-10-28. https://github.com/NVIDIA/TensorRT-LLM/releases/tag/v1.4.0rc2
8. README (Deprecation Policy, Telemetry Data Collection), NVIDIA/TensorRT-LLM, GitHub. https://github.com/NVIDIA/TensorRT-LLM/blob/main/README.md
9. LICENSE, NVIDIA/TensorRT-LLM, GitHub. https://github.com/NVIDIA/TensorRT-LLM/blob/main/LICENSE
10. setup.py at v1.2.1, NVIDIA/TensorRT-LLM, GitHub. https://github.com/NVIDIA/TensorRT-LLM/blob/v1.2.1/setup.py
11. setup.py at v1.3.0rc21, NVIDIA/TensorRT-LLM, GitHub, 2026-07-15. https://github.com/NVIDIA/TensorRT-LLM/blob/v1.3.0rc21/setup.py
12. tensorrt_llm/commands/serve.py at v1.2.1, NVIDIA/TensorRT-LLM, GitHub. https://github.com/NVIDIA/TensorRT-LLM/blob/v1.2.1/tensorrt_llm/commands/serve.py
13. tensorrt_llm/commands/serve.py at v1.4.0rc2, NVIDIA/TensorRT-LLM, GitHub. https://github.com/NVIDIA/TensorRT-LLM/blob/v1.4.0rc2/tensorrt_llm/commands/serve.py
14. tensorrt_llm/serve/openai_server.py at v1.4.0rc2, NVIDIA/TensorRT-LLM, GitHub. https://github.com/NVIDIA/TensorRT-LLM/blob/v1.4.0rc2/tensorrt_llm/serve/openai_server.py
15. tensorrt_llm/llmapi/llm_args.py at v1.4.0rc2, NVIDIA/TensorRT-LLM, GitHub. https://github.com/NVIDIA/TensorRT-LLM/blob/v1.4.0rc2/tensorrt_llm/llmapi/llm_args.py
16. Telemetry, TensorRT LLM developer guide, NVIDIA. https://nvidia.github.io/TensorRT-LLM/developer-guide/telemetry.html
17. Supported Hardware, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/supported-hardware.html
18. Installation Guide, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/installation/installation-guide.html
19. Container Images, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/installation/containers.html
20. Quantization, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/features/quantization.html
21. KV Cache System, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/features/kvcache.html
22. Paged Attention, IFB, and Request Scheduling, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/features/paged-attention-ifb-scheduler.html
23. Overlap Scheduler, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/features/overlap-scheduler.html
24. Feature Combination Matrix, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/features/feature-combination-matrix.html
25. Prometheus Metrics example, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/examples/prometheus_metrics.html
26. PrometheusMetricsConfig API reference, TensorRT LLM, NVIDIA. https://nvidia.github.io/TensorRT-LLM/llm-api/reference/PrometheusMetricsConfig.html
27. nvidia/Llama-3.1-8B-Instruct-FP8 model card, config.json and hf_quant_config.json, Hugging Face. https://huggingface.co/nvidia/Llama-3.1-8B-Instruct-FP8
28. vllm serve CLI reference (--api-key), vLLM. https://docs.vllm.ai/en/latest/cli/serve/
29. Installation (supported hardware), vLLM. https://docs.vllm.ai/en/latest/getting_started/installation/
30. Release v0.32.0, vllm-project/vllm, GitHub, 2026-10-18. https://github.com/vllm-project/vllm/releases/tag/v0.32.0
31. SGLang README (Supported Hardware), sgl-project/sglang, GitHub. https://github.com/sgl-project/sglang
32. Release v0.5.22, sgl-project/sglang, GitHub, 2026-10-19. https://github.com/sgl-project/sglang/releases/tag/v0.5.22; serving and observability args at the tag: https://github.com/sgl-project/sglang/blob/v0.5.22/python/sglang/srt/arg_groups/fields/serving.py
33. tensorrt_llm/version.py on main (1.4.0rc3), NVIDIA/TensorRT-LLM, GitHub, checked 2026-10-28. https://github.com/NVIDIA/TensorRT-LLM/blob/main/tensorrt_llm/version.py
34. vllm/usage/usage_lib.py at v0.32.0, vllm-project/vllm, GitHub. https://github.com/vllm-project/vllm/blob/v0.32.0/vllm/usage/usage_lib.py
35. Triton Inference Server Release 26.08 notes, NVIDIA, updated 2026-10-01. https://docs.nvidia.com/deeplearning/triton-inference-server/release-notes/rel-26-08.html
