GPU Server PSU Redundancy: 4+2, 5+1, N+N, A/B Feeds

How DGX H100 (4+2), DGX B200 (5+1) and DGX B300 (N+N) PSU schemes map onto A/B rack feeds, what a feed loss does, and how to size each circuit.

By GPU Smith

GPU Server PSU Redundancy: 4+2, 5+1, N+N, A/B Feeds

Summary

  1. 01PSU redundancy and feed redundancy are separate design questions: count the supplies left after a whole upstream path fails, then check the documented behavior at that count.
  2. 02H100 documentation conflicts on operation with three powered PSUs. The article advises designing to the SuperPOD guide's four-PSU floor and using three independent upstream paths.
  3. 03B200 can keep running after an A/B feed loss, but its GPUs are capped at 800 W. Four surviving supplies add shutdown margin without restoring full GPU power.
  4. 04The AC B300's twelve PSUs support an inferred 6/6 A/B split that leaves the stated six-PSU minimum energized after one feed fails.
  5. 05Size feeds and phases for failover. Use full system maximum when derated draw is unpublished, trace path independence to the UPS, and keep feed maintenance separate from PSU swaps.
Inside this article
  1. 01Why PSU topology decides the feed design
  2. 02Notation: N+1, 4+2, 5+1, 3+3 and N+N
  3. 03DGX H100: six PSUs, 4+2
  4. 04DGX B200: six PSUs, 5+1, with a documented GPU derate
  5. 05DGX B300: twelve PSUs, N+N
  6. 06HGX OEM servers: 3+3 and 5+1 are configuration choices
  7. 07Mapping PSUs to A/B feeds
  8. 08Phase balance and breaker sizing
  9. 09Failure behavior and power capping
  10. 10Maintenance and hot-swap
  11. 11Design checklist
  12. 12Sources

Why PSU topology decides the feed design

A dual-corded server is usually assumed to survive the loss of either feed. That holds for a 1U server whose two supplies each carry the full load, not automatically for eight-GPU systems: a DGX H100 or B200 has six power supply units, and no vendor-documented scheme promises full operation on half of them. The design question is how many PSUs remain energized when one upstream path fails, and what the server does with that number.

This guide compares NVIDIA's documented schemes for three DGX generations plus two OEM HGX servers, then derives single-path failure outcomes. Vendor statements are quoted from documentation fetched on 2026-10-28; feed mappings and arithmetic are this guide's analysis. General rack sizing is covered in the GPU rack power requirements planning guide.

4+2DGX H100/H200 PSU redundancy with six supplies installed
5+1DGX B200 PSU redundancy with six supplies installed
800 WDGX B200 maximum per GPU after an A/B feed loss
12PSUs installed in the AC version of the DGX B300, configured for N+N redundancy

Notation: N+1, 4+2, 5+1, 3+3 and N+N

N is the count of supplies needed for the rated load; the second number is spares. Only 3+3 (generally N+N) lets an even A/B split survive a whole feed loss at full capability. Two other thresholds are often confused with N: the boot minimum (three PSUs in all three DGX guides, with only the BMC available below that) and the shutdown threshold for a running system. Between N and shutdown lies a degraded band where the system runs but limits power.

A consistency check, derived here rather than stated by NVIDIA, is that N is the smallest PSU count whose combined rating covers the system maximum:

SystemPSUs installedPer-PSU ratingSystem max. inputN × rating(N−1) × rating
DGX H100/H2006 (4+2)3,300 W10.2 kW4 × 3.3 = 13.2 kW3 × 3.3 = 9.9 kW
DGX B2006 (5+1)3,300 W14.3 kW5 × 3.3 = 16.5 kW4 × 3.3 = 13.2 kW
DGX B300 (AC)12 (N+N, N = 6)3.2 kW (table) / 3.3 kW (power spec)15 kW system max.6 × 3.2 = 19.2 kW5 × 3.2 = 16.0 kW

Table 1. PSU counts and ratings from the NVIDIA user guides; the last two columns are derived arithmetic.

For H100 and B200 the (N−1) column falls below the system maximum, consistent with the documented power limiting below N supplies. For B300, N = 6 leaves margin even though five supplies would nominally cover 15 kW.

DGX H100: six PSUs, 4+2

The DGX H100/H200 user guide states that "the system includes six power supply units (PSU) configured for 4+2 redundancy," each rated "3300 W @ 200-240 V, 16 A, 50-60 Hz" [1]. Its power table pairs the "200-240 volts AC" input with "10.2 kW max.", the same layout the B200 guide uses for its 14.3 kW system maximum, and NVIDIA's SuperPOD design guide sizes circuits on 10.2 kW per system at peak (Table 7: 20.4 kW per circuit for four systems) [2].

The two NVIDIA documents conflict on failure behavior. The user guide says that if three PSUs lose power from "a data center issue or power distribution unit failure, the system continues to function, but at a reduced performance level." The SuperPOD guide says "Four of the six power supplies must be energized for the system to operate," and grades a traditional two-feed (2N) layout "Not acceptable for DGX H100 systems" because a feed loss drops a system "below four, resulting in a shutdown." Both pages were rechecked on 2026-10-28 and still disagree; design to the SuperPOD guide's four-PSU floor, the basis of NVIDIA's facility guidance.

DGX B200: six PSUs, 5+1, with a documented GPU derate

The DGX B200 keeps six 3,300 W supplies at 200-240 V and 16 A each but moves to 5+1, with "14.3 kW max." in the input row [3]; the product page lists system power usage as "~14.3 kW max" [4]. The B200 guide is the only one of the three that tabulates what happens as AC cables are pulled:

AC cables removedOperating PSUsEffect (as documented)Max. power per GPU
15No effect on the DGX system1,000 W
24BMC alerts on AC power loss800 W
33BMC alerts on AC power loss800 W
42DGX system shuts downNot applicable

Table 2. DGX B200 behavior on AC cable removal, from the NVIDIA DGX B200 User Guide; the guide notes the per-GPU maximum is reported by nvidia-smi.

Losing two or more supplies costs 200 W per GPU, 1.6 kW of GPU limit across eight GPUs (derived). The derate does not deepen between four and three PSUs, so a fourth surviving supply buys margin above shutdown, not performance. NVIDIA does not publish system wattage in the 800 W state, so the derate cannot be converted into a reduced feed load.

The design question is how many PSUs remain energized when one upstream path fails, and what the server does with that number.

DGX B300: twelve PSUs, N+N

The AC version of the DGX B300 carries "12 power supply units (PSU) configured for N+N redundancy," with "the minimum number of required PSUs" stated as six and the same three-PSU boot minimum [5]. The guide lists power consumption as 14.5 kW and "15 kW system max." for both the 200-240 VAC and 54 VDC inputs. The supply rating appears as both "12 x 3.2 kW" and "3.3 kW @ 200-240 V, 16 A" (unchanged in the 2026-10-21 revision); this guide uses the lower 3.2 kW. The page gives no per-GPU limits by PSU count and does not mention dual-feed wiring; a 6/6 split across two feeds is an inference from the notation.

A busbar version is fed at 54 VDC from in-rack power shelves; NVIDIA's B300 SuperPOD reference architecture describes "six 5.5kW Power Shelves configured as N redundancy" delivering "up to 33kW," and up to four systems per rack [6]. Redundancy then moves to the shelves and their feeds, outside this AC-focused guide; the B300 10 MW capacity worksheet covers facility-scale B300 sizing.

HGX OEM servers: 3+3 and 5+1 are configuration choices

Supermicro's SYS-A21GE-NBRT (HGX B200 8-GPU) lists "6x 5250W Redundant (3 + 3) Titanium Level (96%) Hot-plug power supplies" at 200-240 VAC [7]; three surviving supplies give 3 × 5,250 W = 15.75 kW of nameplate (derived). Dell's XE9680 technical guide (Rev. A09, July 2025) offers six 2800 W or 3200 W supplies in either mode and spells out the difference: "Not Redundant (5+1) FR (System can get full performance)" versus "PSU Redundant (3+3) FTR (System throttles when more than one PSU is down)" [8].

Mapping PSUs to A/B feeds

This table is analysis, assuming PSUs are split evenly across independent paths and one whole path is lost.

SystemLayoutPSUs left after one path lossOutcome (derived from vendor text)
DGX H100A/B, 3+33User guide: runs at reduced performance. SuperPOD guide: shuts down. Treat as not acceptable
DGX H100Three paths, 2+2+24Meets the four-PSU operating floor; NVIDIA's documented design
DGX B200A/B, 3+33Runs, BMC alerts, GPUs capped at 800 W; one further PSU failure shuts the system down
DGX B200Three paths, 2+2+24Runs, GPUs capped at 800 W; tolerates one further PSU failure
DGX B200Any layout with two or more PSUs per path≤ 4800 W per GPU; holding 1,000 W needs at most one PSU per path
DGX B300 (AC)A/B, 6+66Meets the stated six-PSU minimum; no documented derate
Dell XE9680A/B, 3+3 FTR3Runs, throttled per Dell

Table 3. Single-path failure outcomes (analysis).

The less obvious result is the B200: because four PSUs already trigger the 800 W cap, no practical multi-path layout preserves full GPU power through a path loss. NVIDIA's H100 guide adds an upstream caveat: in its plain N+1 pattern two of three rPDUs "are supplied by the same upstream UPS power source," so that UPS failing still powers the system off; only "Enhanced N+1" with three discrete UPS paths is graded "Optimal" [2]. Path independence must be traced to the UPS.

Worked example 1: DGX H100, three paths (reproducing NVIDIA's table)

Assumptions: four systems per rack, 10.2 kW each at peak.

  1. Rack peak: 4 × 10.2 = 40.8 kW; normal load per path 40.8 / 3 = 13.6 kW.
  2. One path lost: 40.8 / 2 = 20.4 kW per surviving path (the 50% rule).
  3. Circuit at 415 V, 32 A, three-phase, 100% breaker rating, 0.95 power factor: √3 × 415 × 32 × 0.95 ≈ 21.85 kW (listed 21.8 kW).
  4. Margin: 21.8 − 20.4 = 1.4 kW, NVIDIA's "stranded capacity".

Worked example 2: two DGX B200 per rack on A/B (illustrative)

Two systems per rack follows NVIDIA's B200 SuperPOD reference architecture [9]; figures are illustrative.

  1. Rack peak: 2 × 14.3 = 28.6 kW; normal load 14.3 kW per feed, 14.3 / 6 ≈ 2.38 kW per PSU.
  2. Feed A lost: carrying 14.3 kW on three PSUs would need 4.77 kW each, above the 3,300 W rating, hence the derate.
  3. Nameplate ceiling on feed B: 6 × 3.3 = 19.8 kW (approximate; the guide does not say whether 3,300 W is input or output).
  4. Conservative sizing uses the full 28.6 kW per feed, since the derated draw is unpublished. One 415 V/32 A circuit (21.8 kW) is insufficient; a 415 V/63 A circuit on a 100%-rated assembly gives √3 × 415 × 63 × 0.95 ≈ 43.0 kW, or each side can use two 32 A circuits.
  5. Sizing to the 19.8 kW ceiling would rely on undocumented firmware limiting; confirm with NVIDIA first.

Worked example 3: two DGX B300 (AC) per rack on A/B (illustrative)

  1. Rack peak: 2 × 15 = 30 kW; normal 15 kW per feed, 1.25 kW per PSU.
  2. Feed lost: six PSUs per system carry 15 kW, 2.5 kW each, below the 3.2 kW rating.
  3. Surviving feed: 30 kW, above 21.8 kW, so a larger circuit or two per side.
  4. Per phase, 12 PSUs at four per phase: 4 × 2.5 = 10 kW, or 10,000 / (240 V × 0.95) ≈ 43.9 A line-to-neutral.
Figure 01
A/B feed loss: DGX B200 versus AC DGX B300
DGX B200A/B, 3+3
  • Three PSUs remain: the system runs, BMC alerts, and GPUs are capped at 800 W.
  • One further PSU failure shuts the system down.
  • The derated system draw is unpublished, so the GPU cap cannot establish a reduced feed load.
DGX B300 (AC)A/B, 6+6
  • Six PSUs remain, meeting the stated six-PSU minimum with no documented derate.
  • The guide gives no per-GPU limits by PSU count; the even feed split is inferred from N+N.

Feed-loss outcomes are the article's analysis, assuming an even PSU split across independent paths and the loss of one whole path.

Phase balance and breaker sizing

rPDUs "typically derive 200-240 VAC single phase power by dividing a three-phase input power circuit," and NVIDIA asks that "each PSU of each system should be connected to a different 'leg' (or phase)," noting that with the three-path N+1 pattern "it takes two racks of systems to balance the phases" [2]. A 3+3 A/B layout maps one PSU per phase per feed. Check imbalance in the failover state, where 100% load can trip what 50% tolerated. DGX cords are C19/C20, 250 VAC, 20 A: six C19 outlets per H100 or B200 and twelve per AC B300 across both feeds.

In North America, NEC 210.20(A) requires the overcurrent device rating to be at least the noncontinuous load plus 125% of the continuous load, i.e. a standard breaker loaded to 80%, except for assemblies listed for 100% operation (IAEI Magazine: 100% vs. 80%, written on the 2014 NEC; the 2023 and 2026 editions keep 210.20(A) with the same 125% rule and 100% exception per UpCodes; use the edition your jurisdiction adopted). Schneider Electric notes that "UL has mandated a de-rating of all components to 80% continuous load" in rack PDUs [10]. NVIDIA's Table 7 applies 100% to the 32 A IEC rows and 80% to the 60 A rows.

One row does not reproduce: for 208 V, 60 A, three-phase delta at 80%, NVIDIA lists 32.8 kW, but √3 × 208 × 60 × 0.8 × 0.95 ≈ 16.4 kW, too little for the 20.4 kW per-circuit peak of four DGX H100 systems. The 32.8 kW figure is close to the 415 V/60 A row (32.7 kW); the row was unchanged on 2026-10-28, so recompute 208 V designs. Inrush is not specified in the three DGX guides; request it from the PSU or rPDU vendor before choosing trip curves.

Failure behavior and power capping

On B200, losing two or more PSUs raises a BMC alert and the lower per-GPU maximum appears in nvidia-smi [3]; the H100 guide says only "reduced performance level," and the B300 guide gives no derate data. Alarm on PSU input loss from the BMC (Redfish or IPMI); one capped node can slow a synchronous multi-node job. The cost of an 800 W cap is workload-dependent; see GPU power cap economics.

Commissioning should include NVIDIA's test of "turning off the individual circuit breakers feeding each rack power strip to verify that power redundancy has been achieved in each rack." On an A/B B200, opening one feed under load should yield a BMC alert and an 800 W limit, not a shutdown.

Maintenance and hot-swap

All three DGX guides require replacing a failed PSU "immediately" and forbid operating "with PSUs depopulated." Live replacement is limited in degraded states: on H100, "if only three PSUs have power, shut down the system before replacing an operational PSU"; the B200 threshold is two. B300 supplies are "front-loaded with rear power connections," so swaps need front and rear access. In practice (analysis), never overlap feed maintenance and PSU swaps on a rack: an A/B B200 with one feed open is one supply from shutdown.

Design checklist

Figure 02
From PSU inventory to a verified feed design
  1. 01Establish the server thresholds

    Record PSU count, N, boot minimum and shutdown threshold for each server model.

  2. 02Trace the worst upstream failure

    Trace paths to the UPS, count the PSUs still energized, and check whether the server runs at full power, derates or shuts down.

  3. 03Size the surviving feed

    Use full system maximum unless the vendor publishes a derated figure. Apply the correct circuit derating and power factor, then check per-phase failover current.

  4. 04Verify alarms and failover

    Wire PSU input-loss alarms into monitoring and record a breaker-by-breaker failover test at commissioning.

  5. 05Plan maintenance and spares

    Keep spares available and make sure feed work and PSU swaps never overlap.

#Check
1PSU count, N, boot minimum and shutdown threshold per server model
2PSUs energized after the worst single upstream failure, traced to the UPS
3Documented behavior at that count (full power, derate, shutdown)
4Per-feed load at failover: full system maximum unless the vendor publishes a derated figure
5Circuit capacity with the correct derating (80% NEC or 100% listed) and power factor
6Per-phase current in the failover state
7C19 outlet count per feed and cord type
8BMC alarms for PSU input loss wired into monitoring
9Breaker-by-breaker failover test recorded at commissioning
10Spares and a rule that feed work and PSU swaps never overlap

Table 4. Per-rack PSU and feed worksheet.

Upstream topology and UPS sizing are treated in electrical design for GPU clusters. GPU Smith can review a proposed PSU-to-feed map on request.

Sources

  1. Introduction to NVIDIA DGX H100/H200 Systems - NVIDIA, 4+2 redundancy, 3300 W per PSU, "10.2 kW max.", boot minimum, replacement rules, cords (page last updated 2026-10-17; accessed 2026-10-28)
  2. Introduction to NVIDIA DGX B200 Systems - NVIDIA, 5+1, 14.3 kW max., cable-removal table (1,000 W/800 W per GPU) (page last updated 2026-10-17; accessed 2026-10-28)
  3. Introduction to NVIDIA DGX B300 Systems - NVIDIA, 12 PSUs N+N, six-PSU minimum, 3.2/3.3 kW, 15 kW max. (page last updated 2026-10-21; accessed 2026-10-28)
  4. NVIDIA DGX B200 - NVIDIA, system power usage "~14.3 kW max" (accessed 2026-10-28)
  5. NVIDIA DGX SuperPOD Data Center Design, DGX H100: Electrical Specifications - NVIDIA, four-PSU requirement, feed-pattern grading, Table 7, phase balancing, breaker test (page last updated 2025-11-19; accessed 2026-10-28)
  6. NVIDIA DGX SuperPOD B200 Reference Architecture: Key Components - NVIDIA, two DGX B200 systems per rack (accessed 2026-10-28)
  7. NVIDIA DGX SuperPOD B300 Reference Architecture: Key Components - NVIDIA, 5.5 kW power shelves in N redundancy, 33 kW, four shelves and up to four systems per rack (accessed 2026-10-28)
  8. Supermicro SYS-A21GE-NBRT - Supermicro, HGX B200 server with 6x 5250W 3+3 redundant supplies at 200-240 VAC (accessed 2026-10-28)
  9. Dell PowerEdge XE9680 Technical Guide - Dell, Rev. A09 July 2025, 5+1 FR vs 3+3 FTR (accessed 2026-10-28)
  10. 50A 208v 3 Phase Rack PDU Load Ratings and Calculations Explained (FA156194) - Schneider Electric, UL 80% rack PDU derating (accessed 2026-10-28)
  11. 100% vs. 80%: Choosing the Right OCPD Solution - IAEI Magazine, NEC 210.20(A) 125% rule and 100%-rated exception (2014 NEC basis) (accessed 2026-10-28)
