Tensor vs Pipeline Parallelism for Inference: NVLink vs PCIe

The decision in one paragraph

When a model does not fit on one GPU, you split either the math inside every layer (tensor parallelism, TP) or the stack of layers (pipeline parallelism, PP). TP cuts per-token latency because every GPU works on every token, but puts two all-reduces per layer on the critical path, so it needs a fast interconnect. PP sends one activation tensor per stage boundary and tolerates slow links, but each token walks through the stages serially. vLLM's documentation states the rule: "if the model is too large for a single GPU but fits on a single node with multiple GPUs, use tensor parallelism", and "if the model is too large for a single node, combine tensor parallelism with pipeline parallelism", with tensor_parallel_size set to GPUs per node and pipeline_parallel_size to the number of nodes ^[1]. The same page carves out the PCIe case: if the GPUs "do not have NVLINK interconnect (e.g. L40S), leverage pipeline parallelism instead of tensor parallelism for higher throughput and lower communication overhead." Below is why, with arithmetic you can redo for your model.

What TP and PP actually communicate

Tensor parallelism. Megatron-LM splits the first MLP matrix by columns and the second by rows, so the MLP needs one all-reduce at its output; attention is split by heads the same way, giving "only two all-reduces in the forward path and two in the backward path" per transformer layer ^[2]. Inference has no backward pass, so the count is two all-reduces per layer per forward step. Sarathi-Serve describes inference TP the same way, "two all-reduce operations per layer – one in attention computation and the other in FFN", and notes that "since these communication operations are in the critical path, TP is preferred only within a single node" ^[3].

Each all-reduce carries the full hidden state, (tokens x hidden size), and no GPU can start the next layer until it completes, so the slowest link sets the pace.

Pipeline parallelism. Each GPU (or TP group) owns a contiguous block of layers and passes the hidden state to the next stage with one point-to-point send. Narayanan et al. give the training version: traffic between consecutive pipeline devices is bsh (batch x sequence x hidden) per micro-batch, whereas TP all-reduces tensors of size bsh "twice each in the forward and backward pass for each layer" ^[4].

PP pays in time instead: a token's forward pass is serial across stages, and stages idle when the schedule cannot keep each one busy (the pipeline bubble). Mixed prefill and decode micro-batches have uneven run times, which makes bubbles worse in inference than in uniform training batches.

vLLM's tuning guide puts the trade-off in one line each: increasing TP "may cause excessive synchronization overhead", while increasing PP "may cause latency penalties" ^[5].

Bandwidth numbers that matter

Datasheet interconnect figures are usually bidirectional totals. A ring all-reduce sends and receives at the same time, so the number to divide by is the per-direction rate.

NVIDIA's Hopper post describes "18 fourth-generation NVLink links to provide 900 GB/sec total bandwidth", each with "25 GB/sec effective bandwidth in each direction" ^[6]. The L40S page lists "PCIe Gen4 x16: 64GB/s bidirectional" and NVLink "No" ^[7]; Gen5 doubles that, so its 128 GB/s is also a bidirectional figure.

These are link rates. Achieved all-reduce bandwidth is lower, and on a PCIe server the ring may cross a switch uplink or the CPU socket interconnect. The H100 NVL's 600 GB/s applies only within a bridged pair: NVIDIA's product brief says the card bridges "with a single adjacent NVIDIA H100 NVL card", so a TP=4 or TP=8 group of H100 NVLs crosses PCIe between pairs. The H200 NVL adds 4-way bridges ^[8].

Per-token communication estimate

This is a derived estimate, not a sourced benchmark: it counts bytes and divides by link rate, ignoring latency, overlap and protocol overhead, so treat outputs as lower bounds.

Inputs.

• L = number of transformer layers, h = hidden size, b = bytes per activation element (2 for BF16).
• T = tokens in the step (decode batch size, or prompt tokens for prefill).
• N = TP degree.

Step 1: message size. Each TP all-reduce reduces a tensor of T x h elements: S = T x h x b bytes.

Step 2: all-reduces per forward pass. Two per layer gives 2L.

Step 3: ring cost. NCCL's performance notes derive that an all-reduce of S bytes over n ranks needs "2(n-1) data transfers", a best-case time of t = S x 2(n-1) / (n x B) with B the per-rank link bandwidth, a factor "independent of the algorithm used (ring, tree, or other)" ^[9]. So each GPU sends (and receives) 2(N-1)/N x S bytes per all-reduce.

Result (estimate). Bytes each GPU sends per forward step:

V_TP = 2L x T x h x b x 2(N-1)/N

and a lower bound on TP communication time is V_TP / B_per_direction. For comparison, PP sends T x h x b bytes once per stage boundary.

Worked example: Llama 3.1 70B

Llama 3 70B has 80 layers, model dimension 8,192, 64 attention heads and 8 key/value heads ^[10]. Activations in BF16, so b = 2.

1. Bytes per token per all-reduce: 8,192 x 2 = 16,384 bytes (16 KiB).
2. All-reduces per token: 2 x 80 = 160. Sum of message sizes: 160 x 16,384 = 2,621,440 bytes, about 2.62 MB per token.
3. Ring factor: 2(N-1)/N = 1.5 at N = 4, 1.75 at N = 8.
4. Per-GPU traffic per token: 2.62 MB x 1.5 = 3.93 MB at TP=4; 2.62 MB x 1.75 = 4.59 MB at TP=8.

Scaled to three step sizes and divided by per-direction rates:

Going from TP=4 to TP=8 raises per-GPU traffic (1.5x to 1.75x the message) while each GPU's compute halves, so communication's share of step time grows with TP degree.

Decode in context. Decode is usually bound by weight reads. With roughly 140 GB of BF16 weights (70B x 2 bytes) split over four H100 SXM GPUs at 3.35 TB/s each ^[11], each GPU reads 35 GB per step, a floor of about 10.4 ms. At batch 64, NVLink adds 0.56 ms of transfer (about 5%). The same bytes over PCIe Gen5 would add 3.9 ms (about 38%) unless overlapped.

Latency, not bandwidth, at batch 1. At batch 1 the bandwidth term is microseconds, but 160 all-reduces run one after another in each step. If each costs a fixed 5 to 25 µs (an assumption; measure it), that is 0.8 to 4 ms per token from launch and synchronization latency alone. Small-batch interactive serving therefore feels TP overhead even when bandwidth looks ample.

Prefill in context. A 4,096-token prefill of a 70B model is about 2 x 70e9 x 4,096 = 5.7e14 FLOP. Four H100 SXM at half the 1,979 TFLOPS BF16 sparsity figure ^[11], assuming 50% utilization, need about 290 ms. NVLink's 36 ms is small next to that; PCIe Gen5's 252 ms is nearly as large as the compute, so without overlap TP over PCIe can nearly double time to first token on long prompts.

PP comparison. At batch 64 a stage boundary carries 64 x 16,384 = 1 MiB (16 µs at 64 GB/s), about 240 times less than TP=4's 252 MB per GPU.

TP on PCIe: when it still works

TP over PCIe is tolerable with:

• Small TP degree. TP=2 has a ring factor of 1.0; use it when the model just misses one card.
• Short prompts, moderate batches, where the decode bandwidth term is a few milliseconds against a weight-read floor several times larger (see the L40S numbers below).

The L40S case shows the cost. Take Llama 3.1 70B with FP8 weights (about 70 GB) on four L40S cards (48 GB, 864 GB/s each; NVIDIA L40S):

• TP=4. Each GPU reads about 17.5 GB per decode step, a floor of about 20 ms. At batch 64, BF16 all-reduce traffic adds about 7.9 ms at 32 GB/s, roughly 39% on top, plus per-message latency.
• PP=4. Each stage also reads about 17.5 GB in about 20 ms, but a token crosses all four stages, so per-token latency is about 81 ms. With four micro-batches in flight, aggregate tokens per second can match TP's while the links carry only 1 MiB per boundary.

These idealized estimates match vLLM's L40S advice: PP for aggregate throughput, TP for lower inter-token latency if you can afford the PCIe tax. Four micro-batches of 64 means 256 concurrent sequences, so PP needs enough KV cache and load. For card-level trade-offs on PCIe-only servers see RTX PRO 6000 vs L40S.

When pipeline parallelism wins

• Across nodes. Narayanan et al.'s first takeaway is that "tensor model parallelism should generally be used up to degree g when using g-GPU servers, and then pipeline model parallelism can be used to scale up to larger models across servers" ^[4]. That is a training result, but the reasoning (all-reduce on slow links) carries over.
• Inference evidence. Sarathi-Serve ran Falcon-180B on two 4xA100 nodes "connected over 100 Gbps Ethernet". TP-8 had median decode latency "∼ 2× higher" than TP-4 x PP-2 "because TP incurs high communication overhead due to cross-node all-reduces". With their bubble-reducing scheduler they report "up to 5.6× gains in end-to-end serving capacity" for that deployment ^[3]. The 5.6x is against a 2024 vLLM baseline and measures scheduling, not PP alone.
• Throughput-oriented serving on PCIe cards, as above.
• GPU counts TP cannot use, covered next.

PP loses at low concurrency with tight inter-token latency targets: stages sit idle and each token pays the full serial path.

GPU count granularity

vLLM rejects any TP size that does not divide the attention head count: "Total number of attention heads (...) must be divisible by tensor parallel size". KV heads are divided by the TP size, and replicated when there are fewer KV heads than ranks, "so each GPU has at least one KV head" (vLLM source, vllm/config/model.py, v0.32.0 tag, released 2026-10-18).

For Llama 3 70B (64 query heads, 8 KV heads):

A 6-GPU box therefore runs TP=2 x PP=3, or PP=6 with uneven stages (14, 14, 13, 13, 13, 13 layers). vLLM notes PP "splits the model along layers and supports uneven splits", and recommends tensor_parallel_size=1 with pipeline_parallel_size equal to the GPU count when the count does not divide the model ^[1]. The 14-layer stages then set throughput. For PaLM 540B on TPU v4, Pope et al. "padded the number of attention heads up from 48 to 64 in order to partition more" effectively ^[12].

Multi-node: keep TP inside the node

vLLM's multi-node examples run --tensor-parallel-size 8 --pipeline-parallel-size 2 on two 8-GPU nodes, with Ray (--distributed-executor-backend ray) or multiprocessing (--nnodes, --node-rank, --master-addr). If NCCL_DEBUG=TRACE logs show [send] via NET/Socket, "NCCL used a raw TCP socket, which is not efficient for cross-node tensor parallelism"; look for NET/IB/GDRDMA instead ^[1].

The Megatron papers behind this layout report training results, not inference:

• Shoeybi et al. trained models "up to 8.3 billion parameters using 512 GPUs" with intra-layer TP, reporting 15.1 PetaFLOPs at 76% scaling efficiency ^[2].
• Narayanan et al. combined TP within DGX A100 servers, PP across them and data parallelism: 502 petaFLOP/s on 3,072 GPUs for a 1-trillion-parameter model, 52% of peak per-GPU throughput. They found "sub-optimal combinations of tensor and pipeline model parallelism can lead to up to 2× lower throughput, even with high-bandwidth network links between servers" ^[4].

Training adds backward-pass and gradient traffic that inference lacks, so treat these as evidence for the topology rule, not inference figures. The exception is a scale-up domain larger than a server (NVLink Switch racks), where the NVLink domain is the boundary; see NVLink 5 vs NVLink 6. For MoE models see MoE expert parallelism sizing.

Interaction with MFU and batch size

Pope et al. built an analytical model for choosing inference partitionings on TPU v4 (270 GB/s interconnect per chip) ^[12]. In their 1D layout, the Megatron-style split, communication time per layer is about 2BLE / bandwidth (batch x length x embedding) and does not shrink as chips are added, while compute does. That is the same effect as the rising per-GPU bytes above. They also found the best layout changes with tokens per batch, reporting 29 ms per token at low batch (int8 weights) and 76% MFU on large-batch prefill for PaLM 540B. These are TPU results, not GPU results.

In practice: small-batch decode is latency-bound, so TP's per-message cost dominates. Large-batch decode is weight-read-bound, so the bandwidth term scales with link speed. Long prefills are compute-bound, and the PCIe bandwidth term can match compute time. Chunked prefill caps tokens per step, so it also caps each all-reduce.

Test plan with NCCL tests

Measure before you choose:

1. Sweep sizes. ./build/all_reduce_perf -b 8 -e 128M -f 2 -g 8 starts at 8 bytes, doubles each step and uses 8 GPUs ^[13]; use -g 4 for a 4-GPU group.
2. Read small-message time at 16 KiB to 1 MiB: that is your per-all-reduce latency at decode batch sizes. Multiply by 2L for per-step overhead.
3. Read busbw at large sizes (busbw = algbw x 2(n-1)/n, per NCCL tests PERFORMANCE.md) and use it instead of the datasheet rate in the estimate.
4. Test the real groups. On PCIe servers, test GPUs under one switch separately from GPUs across sockets.
5. Confirm in the engine with TP=N, PP=N and a hybrid under your real prompt lengths and concurrency, comparing time to first token, inter-token latency and goodput.

Algorithm and protocol choice shifts these curves; see NCCL algorithms and protocols.

Recommendations table

All rows are starting points to confirm with the test plan. GPU Smith helps teams with this kind of parallelism and interconnect sizing.
